IRONHEAD XL

DRAG SPECIALTIES SEATS &
SHOCK ABSORBERS SISSY BARS
•Shock bodies are steel construction with multi- 1310
1310‑0747-0747
stage velocity-sensitive hydraulic dampers
•Feature progressive rate springs that provide a softer
initial response, but resist bottoming better than stock springs EXHAUST
•Improved damping rates for a more controlled ride with no wallowing
•5-position adjustable spring pre-load (adjusting tool included)
•Chrome-plated covers and springs for style
•Custom lengths available for stock ride height or a lowered, custom look CARBURETORS
•Manufactured to Drag Specialties specifications by Progressive Suspension & AIR FILTERS
•Sold in pairs
•Made in the U.S.A.
NOTE: Lowering the motorcycle will reduce ground and
cornering clearance. ENGINE
NOTE: When installing replacement shocks on 79-85 XL models, it may be
necessary to modify or space the chain guard/ belt guard to allow
proper shock clearance.
NOTE: All Drag Specialties shocks are TÜV approved. TRANSMISSION
NOTE: Heavy Duty Applications are recommended for bikes that are & DRIVELINE
operated at or near the manufacturer’s maximum load rating over
50% of the time.
NOTE: Before purchasing or attempting to install shocks that are different 1310-0636
than the OEM length, confirm that your wheel travel can be altered GASKETS
without causing clearance issues such as swingarm/ axle to exhaust & SEALS
contact as well as chain/ belt guard or tire contact.
HEAVY DUTY
FITS MODEL COLOR 279 MM (11”) 292 MM (11,5”) 330 MM (13”) ELECTRICAL
For 79-85 XL, 77-78 XLCR, 83-84 XR1000 Chrome 1310‑0631 1310‑0637 1310‑0650 & LIGHTING
Black 1310‑0741 1310‑0745 1310‑0747

STANDARD
FITS MODEL COLOR 279 MM (11”) 292 MM (11,5”) 318 MM (12,5”) 330 MM (13”) HANDLEBARS,
For 79-85 XL, 77-78 XLCR, 83-84 XR1000 Chrome 1310‑0630 1310‑0636 1310‑0643 1310‑0649 CONTROLS &
Black 1310‑0740 1310‑0744 1310‑0746 ‑ MIRRORS

255 MM (10”) STRUTS
•0,120” wall DOM
steel construction CHROME SHOCK COVER CABLES
•1 /8” o.d. shafts with 0,120” wall
1
TIG welded sleeves KITS FOR PROGRESSIVE
1
• /2” i.d. mounting stud holes SHOCKS
•Matte black electroplated finish •Available for Progressive 412 series
•CNC lathe turned ends shocks on various H-D models BRAKES
•255 mm (10”) length (eyelet center-to-center) •Sold in pairs
•Sold in pairs PART # DESCRIPTION
PART # DESCRIPTION PS5027C Top and bottom covers for 279 mm (11”) Progressive
1304‑0538 255 mm (10”) struts shocks (DS-310092) 77-85 XL and 83-85 XR1000 models OIL TANKS,
FILTERS &
REAR SHOCK CHROME GAS TANKS
BUSHINGS SHOCK
•Replacement TOP CAPS
rubber bushings DASHES
•Designed for •For all swingarm Harleys with stock shocks CHROMED SHOCK & GAUGES
3
use in • /8” longer than stock for a better fit
OEM-style shocks •Come with polished stainless steel clamps, TOP STUD COVERS
•Sold in kit of four screws and nuts •Sold in pairs CHASSIS,
•Made in the U.S.A. •Sold in pairs PART # DESCRIPTION SUSPENSION,
PART # DESCRIPTION PART # DESCRIPTION DS‑310012 For 82-85 XL; repl. FENDERS
0431‑0435 For 54-74 XL; repl. OEM #85210-42A DS‑310040 For 57-78 XL; repl. OEM #s 54704-52 and 54705-52 OEM #54707-88A & WHEELS

SHOCK STUDS DS-310177 DS-310186 FLOORBOARDS
•Zinc-plated studs are available in upper and & PEGS
lower styles
•Nylock nuts are cadmium-plated and cup
washers are chrome-plated DS-175032
•Studs are sold separately
•Made in the U.S.A. DS-310179 HARDWARE
PART # DESCRIPTION PART # DESCRIPTION
UPPER SHOCK STUDS NUTS AND WASHERS
DS‑310177 For 75-78 XL; repl. OEM #54515-75 DS‑175032 5 /8”-18 thin nylock nuts (2-pk.); repl. OEM #7993
DS‑310176 For 57-74 XL; repl. OEM #54515-56B DS‑310186 Cup washers 3 /8” i.d. (10-pk.); repl. OEM #54543-65
LOWER SHOCK STUDS DS‑310187 Cup washers 5 /8” i.d. (10-pk.); repl. OEM #54544-65 GENERAL
DS‑310179 For 75-78 XL; repl. OEM #54516-75 DS‑310188 Cup washers 1 /2” i.d. (10-pk.); repl. OEM #54545-65
DS‑310178 For 57-74 XL; repl. OEM #54516-72
