IRONHEAD XL

DUAL-CABLE THROTTLE
SEATS & ASSEMBLY KITS DS-223210
SISSY BARS •Each kit includes a two-cable throttle assembly with
matching grips, throttle sleeve, OEM-style throttle and
idle cables and hardware
•Designed for early-style S&S Super E & G carbs or any other
butterfly-type carburetor with 81-95 OEM-style throttle linkage
EXHAUST
•Measured from throttle grip to end of cable housing; barrel
fittings are soldered in place (not for CV carbs)
•90° elbows
•Made in the U.S.A.
CARBURETORS PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
& AIR FILTERS DS‑223210 99 cm (39”) throttle assembly kit DS‑223211 106,5 cm (42”) throttle assembly kit DS‑223212 122 cm (48”) throttle assembly kit
DS‑223242 99 cm (39”) throttle cable DS‑223214 106,5 cm (42”) repl. throttle cable DS‑223218 122 cm (48”) repl. throttle cable
DS‑223243 99 cm (39”) idle cable DS‑223215 106,5 cm (42”) repl. idle cable DS‑223219 122 cm (48”) repl. idle cable

ENGINE
DS-223213 0632-0626

TRANSMISSION
& DRIVELINE
0632-0629
GASKETS
& SEALS WHISKEY THROTTLE
S&S UNIVERSAL ASSEMBLIES
THROTTLE ASSEMBLY KIT •Cast aluminum clamshell and throttle tube
ELECTRICAL •Includes a dual cable throttle assembly with cables, •Includes chrome-plated steel cable ferrules
and plated Allen cap clamshell mounting hardware
& LIGHTING matching grips and hardware •Available in two styles: single cable for custom applications or dual
•Designed for use with S&S series B, D or two-throat carbs as well as cable for retrofitment on OEM push/ pull throttle cable assemblies
many universal applications •Cable ferrules included with both styles are designed to fit stock H-D
HANDLEBARS, •Cables measured from throttle grip to end of cable housing thread-in and clip-in cables
CONTROLS & •Made in the U.S.A. •Throttle grip tube is machined to accept rubber motorcycle grips
MIRRORS NOTE: Not for Super E & G series or CV carbs. PART # DESCRIPTION
PART # DESCRIPTION SINGLE CABLE
DS‑223213 122 cm (48”) universal throttle assembly kit 0632‑0626 Polished
DS‑223220 Repl. throttle cable (used as both throttle and idle cable) 0632‑0627 Black
CABLES DUAL CABLE
0632‑0628 Polished
0632‑0629 Black

BRAKES

0632-0589
OIL TANKS, WHISKEY THROTTLE TUBE
FILTERS & •CNC-machined 6061 T-6 aluminum throttle tube
GAS TANKS •Allows owners to replace the thick, generally uncomfortable stock
molded one-piece grips with soft aftermarket grips BILLET THROTTLE TUBE
•The CNC-machined cable channel has barrel openings for two cables •Fully CNC-machined from billet aluminum with a precision diamond
DASHES PART # DESCRIPTION PART # DESCRIPTION knurl pattern that ensures no-slip grip performance
& GAUGES 0632‑0589 Polished 0632‑0700 Black •Special hard black anodized finish for exceptionally smooth action
and durability over plastic units
•Works super smooth due to the precise bore finish; works especially
CHASSIS, well with a light coating of lithium grease
SUSPENSION, •Works perfectly with Joker’s JX and Dual Cable style throttle housings
FENDERS •Accepts all late-model dual Harley-Davidson throttle cables (accepts
& WHEELS 1 /4” round or cylindrical cable lugs)
•Made in the U.S.A.
PART # DESCRIPTION
FLOORBOARDS DS-243128 0632-0545 0632‑0203 Billet throttle tube
& PEGS
THROTTLE ASSEMBLIES
•Complete throttle assemblies
•Include matching left-hand grip
HARDWARE
•Accept thread-in cables
PART # DESCRIPTION THROTTLE SLEEVE
DS‑243127 Chrome throttle/ grip assembly, single cable
for 73-81 XL; repl. OEM #56500-79 •36 mm o.d. (1,4”) sleeves are available in black
DS‑243128 Chrome throttle/ grip assembly, dual cable •Fit most grips
GENERAL for 84-85 XL; repl. OEM #s 56395-81, 56220-81B •Sold each
0632‑0545 Black throttle/ grip assembly, dual cable for PART # DESCRIPTION
84-85 XL; repl. OEM #s 56395-81, 56220-81B DS243110 For 82-85 XL
