Page 646 - Oldbook 2017

IRONHEAD XL

SEATS &
SISSY BARS

EXHAUST

2010‑0899 2010‑0788
CARBURETORS
& AIR FILTERS
2010‑1072
2010‑0612
2010‑1066
ENGINE
BOBBER STYLE TAILLIGHT/ LICENSE PLATE ASSEMBLIES
•Stainless steel or black light housing with a choice of brass or black grille on
1928 Ford style and a red glass lens
TRANSMISSION •Black powder‑coated backing plate
& DRIVELINE •Available in side‑mount or OEM styles
3
•Side‑mount style features 19 mm ( /4”) mounting hole
•1928 Ford style is a 12V single‑filament dual‑bulb design
•Willy’s style is a dual‑function 12V LED style 2010‑0790
GASKETS •Made in the U.S.A. 2010‑1056
& SEALS NOTE: Side mount license plate assemblies will not fit OEM axles on 54-78 XL models.
PART # DESCRIPTION PART # DESCRIPTION
1928 FORD STYLE 1932 FORD STYLE (CONT)
2010‑0588 Vertical side mount, stainless steel light 2010‑0902 Vertical radius side mount, black light
ELECTRICAL 2010‑0898 Vertical side mount, black light 2010‑0683 Horizontal side mount, stainless steel light
& LIGHTING 2010‑0614 Vertical radius side mount, stainless steel light 2010‑0904 Horizontal side mount, black light
2010‑0897 Vertical radius side mount, black light 2010‑0794 Original equipment mount, stainless steel light
2010‑0682 Horizontal side mount, stainless steel light 2010‑0905 Original equipment mount, black light
HANDLEBARS, 2010‑0899 Horizontal side mount, black light 2010‑0684 Repl. lens
CONTROLS & 2010‑0793 Original equipment mount, stainless steel light 1940 FORD STYLE
MIRRORS 2010‑0900 Original equipment mount, black light 2010‑0787 Vertical side‑mount, stainless steel light
2010‑1065 Vertical side mount, stainless steel housing with brass grille 2010‑0786 Vertical radius side‑mount, stainless steel light
2010‑1070 Vertical side mount, black housing with black grille 2010‑0785 Horizontal side‑mount, stainless steel light
2010‑1075 Vertical side mount, black housing with brass grille 2010‑0788 Original equipment mount, stainless steel light
CABLES 2010‑1064 Vertical radius side mount, stainless steel housing 1950 PONTIAC STYLE
with brass grille 2010‑0791 Vertical side‑mount, stainless steel light
2010‑1069 Vertical radius side mount, black housing with black grille 2010‑0913 Vertical side‑mount, black light
2010‑1074 Vertical radius side mount, black housing with brass grille 2010‑0790 Vertical radius side‑mount, stainless steel light
2010‑1066 Horizontal side mount, stainless steel housing with brass grille 2010‑0912 Vertical radius side‑mount, black light
BRAKES 2010‑1071 Horizontal side mount, black housing with black grille 2010‑0789 Horizontal side‑mount, stainless steel light
2010‑1076 Horizontal side mount, black housing with brass grille 2010‑0914 Horizontal side‑mount, black light
2010‑1067 Original equipment mount, stainless steel housing 2010‑0792 Original equipment mount, stainless steel light
with brass grille 2010‑0915 Original equipment mount, black light
OIL TANKS, 2010‑1072 Original equipment mount, black housing with black grille WILLY’S STYLE, LED
FILTERS & 2010‑1077 Original equipment mount, black housing with brass grille 2010‑1055 Vertical side mount, stainless steel light
GAS TANKS 1932 FORD STYLE 2010‑1054 Vertical radius side mount, stainless steel light
2010‑0612 Vertical side mount, stainless steel light 2010‑1056 Horizontal side mount, stainless steel light
2010‑0903 Vertical side mount, black light 2010‑1053 Original equipment mount, stainless steel light
2010‑0613 Vertical radius side mount, stainless steel light
DASHES
& GAUGES

CHASSIS,
SUSPENSION,
FENDERS
& WHEELS

FLOORBOARDS 2010‑1058 2010‑1059 2010‑1060 2010‑1061 2010‑1062
& PEGS
1928 FORD TAILLIGHT GRILLES SPYDER TAILLIGHT OVERLAYS
•Fits all NYC Choppers 1928 Ford style taillights •For NYC Choppers 1950 Pontiac style taillights
•Aluminum construction and available in polished, black or brass finish •Available in chrome or black finish
•Made in the U.S.A. •Made in the U.S.A.
HARDWARE
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
2010‑1058 Polished 2010‑1060 Brass 2010‑1061 Chrome
2010‑1059 Black 2010‑1062 Black

TAILLIGHT/ LICENSE PLATE MOUNT CONDUIT
GENERAL •Attaches behind side mount taillight/ license plate frames with tabs
•Hides and protects wires PART # DESCRIPTION
•45,5 cm L (18”) 2120‑0386 Taillight/ license plate mount conduit

644 ALL PART NUMBERS IN BLUE ARE NEW
