                                            GAS SHOCKS
                                             FOR POLARIS                                                                  GENERAL
                                                                                                                          ACCESSORIES
                 •Quality replacement rear shocks at an affordable price
                 FITS MODEL                  OEM #              PART #  FITS MODEL                OEM #             PART #  RACKS &
                 Trail Blazer 250 94-98      7041448            60-321  Sportsman 400 4x4 95      7041448           60-321  ACCESSORIES
                 Trail Boss 250 R/ES 88      7041448            60-321  Sport 400L 96-97          7041448           60-321
                 Trail Boss 250 88, 95-99    7041448            60-321  Magnum 425 95             7041448           60-321
                 Xpress/Xplorer 300 95-99    7041448            60-321                                                    TRUNKS,
                                                                                                                          LUGGAGE &
                                                                                                                          STORAGE

                                                                                                                          BODY


                                                                                    1310-1384                             ARMOR

                                        429 SERIES SHOCKS                                                                 HANDLEBARS
                                                                                                                          & CONTROLS
                 •The 429 Series shocks have been designed to improve handling and stability while cruising and when
                 at full payload
                 •Heavy-duty spring for riders operating their UTV at or near the manufacturer’s maximum load over        WHEEL
                 50% of the time                                                                                          ACCESSORIES
                 •Features a steel monotube
                 •Internal Floating Piston (IFP)
                 •High-pressure, nitrogen-charged dampers
                 •Powdercoated coil spring                                                                                BRAKES
                 •Stylish shock that cleans up easily
                 •Easy to bolt on and easy to tune via threaded preload adjusters
                 •Require no other mods and can be installed with basic tools                                             BELTS, CHAINS
                 •Sold in pairs                                                                                           & SPROCKETS
                 DESCRIPTION                                  PART #  DESCRIPTION                                 PART #
                 FOR POLARIS RANGER 800 RZR 09-10                    FOR YAMAHA YXR450FA RHINO 4X4/ YXR660FA RHINO 4X4 04-13
                 Front, 41,5 cm (16,25”)                      1310-1387  Front, 40 cm (15,7”)                     1310-1384  DRIVETRAIN
                 Rear, 47 cm (18,5”)                          1310-1386  Rear, 39,5 cm (15,5”)                    1310-1385

                                                                                                                          SUSPENSION


                                                                                                                          ENGINE


                                                                                                                          FUEL/AIR
                                                                                                                          SYSTEMS
                                     512 SERIES REAR SHOCKS
                 •Increase ground clearance and wheel travel 25 mm - 50 mm (1” - 2”) on most models                       ELECTRICAL
                 •Rugged double-steel-wall construction
                 •Progressive rate springs for comfortable ride and improved load-carrying capacity
                 •Five-position spring pre-load adjustment for varying loads                                              LIGHTING
                 •Gas charged for fade-free operation
                 •Durable fabric Shock Sox are included to protect shocks from rock, sand and mud damage
                 •Shock Sox are easily removable with hook-and-loop fasteners for cleaning and adjustments
                 •Not compatible with lift kits                                                                           RIDER
                 FITS MODEL                FRONT PART #     REAR PART #  FITS MODEL            FRONT PART #      REAR PART #  ACCESSORIES
                 HONDA                                               KAWASAKI
                 TRX250/ES Recon 97-12     -                PS-1021B 1  KVF300 Prairie 99-02 (all)  -            PS-1016B 1
                 TRX300 2x4 93-00          -                PS-1002B 1  KVF360 Prairie 03-13 (all)  -            PS-1016B  HARDWARE &
                 TRX300 4x4 93-00          PS-1003B         PS-1002B 1  KVF400 Prairie 97-02   -                 PS-1016B 1  MERCHANDISING
                 TRX350 Rancher 4x4 00-06 (all)  1310-0101  1310-0100  YAMAHA
                 TRX400FW 4x4 95-03        PS-1008B         -        YFZ Banshee 87-06         1310-0372         -
                 TRX450S/ES 4x4 98-04      PS-1009B         PS-1011B  YFM350X Warrior 89-04    1310-0373         -        INDEX
                 TRX500 Rubicon 4x4 01-04  1310-0062        1310-0063  1   Only one shock per rear application.

                    All part numbers in BOLD MAGENTA   2017 PARTS EUROPE ATV/UTV                                            495
                          are new this year.
