Page 59 - Water 2017

www.partseurope.eu ENGINE

HIGH-PERFORMANCE 2-CYCLE WATERCRAFT PISTONS (CONT)
APPAREL
COMPLETE PISTON REPL. REPL. WRIST REPL. REPL. TOP
CC DISPL. BORE SIZE KIT PART # RING PIN CIRCLIP END BEARING
KAWASAKI (CONT)
750 ALL TWIN CYLINDER MODELS 92-95 WITH 20MM WRIST PINS
743cc 80mm/ std. WK1059 0910-0003 3150TD S-512X CW20 B1023 SUNGLASSES
752cc 80.5mm/.5mm WK1060 0910-0001 3169TD S-512X CW20 B1023 & GOGGLES
760cc 81mm/1.0mm WK1061 - 3189TD S-512X CW20 B1023
771cc 81.5mm/1.5mm WK1062 813M08150 - - CW20 B1023
779cc 82mm/2.0mm WK1063 - 3228TD S-512X CW20 B1023
750 ALL TWIN CYLINDER MODELS 96-02 (NOT FOR SS OR SX MODELS)/ 750 ALL TWIN CYLINDER MODELS 92-95 WITH 22MM WRIST PINS
743 80mm/ std. WK1241 809M08000 - - CW22 B1030 ACCESSORIES
752 80.5mm/.5mm WK1242 809M08050 - - CW22 B1030
760 81mm/1.00mm WK1243 809M08100 - - CW22 B1030
900 ALL THREE CYLINDER MODELS 95-04
891cc 73mm/ std. WK1100 - 2874CD S-512X CW20 B1023
903cc 73.5mm/.5mm - 659M07350 2894CD S-512X CW20 B1023 PROPULSION,
915cc 74mm/1.0mm WK1102 - - S-512X CW20 B1023 DRIVELINE
1100 ALL THREE CYLINDER MODELS (EXCEPT 1100 DI MODELS) & HANDLING
1071cc 80mm/ std. WK1246 809M08000 - - CW22 B1030
1083cc 80.5mm/.5mm WK1247 809M08050 - - CW22 B1030
1097cc 81mm/1.0mm WK1248 809M08100 - - CW22 B1030
1500 FOUR CYLINDER FOUR-STROKE MODELS 09-10 ENGINE
1498cc - - - - - 0913-0081 -
POLARIS
650 ALL THREE CYLINDER MODELS
647cc 65mm/ std. - 624M06500 2559CD S-280 CW18 B1014
656cc 65.5mm/.5mm - - 2579CD S-280 CW18 B1014
665cc 66mm/1.0mm - 624M06600 2598CD S-280 CW18 B1014 GASKETS
675cc 66.5mm/1.5mm - - 2618CD S-280 CW18 B1014 & SEALS
685cc 67mm/2.0mm - - 2638CD S-280 CW18 B1014
700 ALL TWIN CYLINDER MODELS
700cc 81mm/ std. - - 3189TD - CW20 0924-0124
710cc 81.5mm/.5mm WK1138 - 3209TD - CW20 0924-0124 FUEL/AIR
718cc 82mm/1.0mm WK1139 - 3228TD - CW20 0924-0124 SYSTEMS
750 ALL THREE CYLINDER MODELS
744cc 69.75mm/ std. WK1075 633M06975 2746CD S-343 CW18 B1014
755cc 70.25mm/.5mm - 633M07025 2766CD S-343 CW18 B1014
766cc 70.75mm/1.0mm WK1077 633M07075 2786CD S-343 CW18 B1014
783cc 71.5mm/.2mm WK1128 - 2815CD S-343 CW18 B1014 BODY
900 ALL THREE CYLINDER MODELS
889cc 74.5mm/ std. - - 2933TD S-512X CW20 0924-0124
901cc 75mm/.5mm - - 2953TD S-512X CW20 0924-0124
913cc 75.5mm/1.0mm - - 2973TD S-512X CW20 0924-0124
1050 ALL THREE CYLINDER MODELS HANDLEBARS
1051cc 81mm/ std. - - - S-512X CW20 0924-0124 & CONTROLS
1064cc 81.5mm/.5mm WK1308 - - S-512X CW20 0924-0124
1077cc 82mm/1.0mm WK1309 781M08200 - S-512X CW20 0924-0124
SEA-DOO (BOMBARDIER)
580 ALL TWIN CYLINDER MODELS
580cc 76mm/ std. - 734M07600 2992TD S-477 CW18 B1003
588cc 76.5mm/.5mm WK1252 734M07650 3012TD S-477 CW18 B1003 ELECTRICAL
595cc 77mm/1.0mm WK1253 734M07700 3032TD S-477 CW18 B1003
602cc 77.5mm/1.5mm - 734M07750 3051TD S-477 CW18 B1003
650 ALL TWIN CYLINDER MODELS
650cc 78mm/ std. - 663M07800 3071LK S-512X CW20 0924-0124
658cc 78.5mm/.5mm WK1117 663M07850 3091LK S-512X CW20 0924-0124 LUBES
666cc 79mm/1.0mm WK1118 663M07900 - S-512X CW20 0924-0124
XP, XH750 718CC 95; SPX, GTI, HX 96
718cc 82mm/ std. - - - S-512X CW20 -
726cc 82.5mm/.5mm - - 3248LK S-512X CW20 -
735cc 83mm/1.0mm - - - S-512X CW20 - TRANSPORT
718 ALL TWIN CYLINDER MODELS & TRAILER
718cc 82mm/ std. WK1295 775M08200 - S-512X CW20 -
726cc 82.5mm/.5mm WK1296 - - S-512X CW20 -
735cc 83mm/1.0mm WK1297 775M08300 - S-512X CW20 -
780 ALL TWIN CYLINDER MODELS
780cc 82mm/ std. WK1300 779M08200 - S-461 CW20 - TOOLS
791cc 82.5mm/.050 - 779M08250 - S-461 CW20 -
801cc 83mm/1.0mm WK1303 779M08300 - S-461 CW20 -
951 ALL TWIN CYLINDER MODELS 98-07
951cc 88mm/ std. - 716M08800 - - CW21 -
960cc 88.5mm/.5mm 0903-1171 716M08850 - - CW21 -
971cc 89mm/1.0mm WK1213 4 716M08900 - - CW21 - MERCHANDISING
WET JET
440 CAYUNA ENGINE THROUGH 88
429cc 67.5mm/ std. - - 2658CD S-256 CW16 -
433cc 67.75mm/.25mm - - 2668CD S-256 CW16 -
436cc 68mm/1.0mm - - 2677CD S-256 CW16 -
INDEX
4 Not for DI models.
HIGH-PERFORMANCE 2-CYCLE WATERCRAFT PISTONS continued on next page.
All part numbers in BOLD MAGENTA 2017 PARTS EUROPE WATERCRAFT 59
are new this year.
