www.partseurope.eu TOOLS

APPAREL

SUNGLASSES
& GOGGLES

3801-0030 ACCESSORIES

TIMING KIT
FOR 2-STROKE WATER-COOLED ENGINES PROPULSION,
DRIVELINE
•Kit includes a dial indicator with extensions and a 14mm spark plug thread adapter & HANDLING
•Allows inspection and adjustment of ignition timing
•Designed to clear frame tubes on most recent water-cooled models 3801-0029
•Gauge face size 1 /2”
1
•Adapter kit (sold separately) allows kit to be used on air-cooled engines; includes an
extended thread adapter and dial indicator extension ENGINE
DESCRIPTION PART # DESCRIPTION PART #
Timing kit for water-cooled 2-stroke engines 3801-0030 Adapter kit for air-cooled engines 3801-0029

GASKETS
& SEALS

IGNITION SYSTEM TESTER STANDARD SPARK FUEL/AIR
•Tests the integrity and strength of an ignition system PLUG WRENCH SYSTEMS
•Spark gap is adjustable from 0-10mm – the larger the gap the spark will jump, •Handle can be custom bent to better fit your application
the stronger the ignition system 3
•Will test the ignition systems of most motorcycles, watercraft, ATVs •Fits standard /16” plug size
•Made in the U.S.A.
and snowmobiles
BODY
PART # MP08-122 PART # M204
P08-147
HANDLEBARS
& CONTROLS
SPARK PLUG GAP TOOL
•Ideal tool for checking and setting spark plug
3801-0284
gap on almost any spark plug
RATCHET SPARK PLUG WRENCH •Includes 0.5mm, 0.6mm, 0.7mm, 0.8mm, 0.9mm ELECTRICAL
and 1.0mm gap gauges
•Designed to fit in limited space on many water-cooled •Machined from billet 6061 aluminum
2-stroke engines •Includes bottle opener on opposite end
•Ratchet mechanism works one way; turn over to reverse •Durable blue anodizing
3
•Fits standard /16” plugs •Laser etched markings for easy identification
DESCRIPTION PART # •Designed by Motion Pro LUBES
Ratchet plug wrench P08-147
3 /16” extension socket 3801-0284 PART # 3805-0126

TRANSPORT
& TRAILER

TOOLS

METRIC TAP AND DIE SET
•Works great for cutting new threads as well as chasing threads that may have been damaged MERCHANDISING
•Manufactured from quality, uncoated high-speed steel for durability and precision cutting
•40-piece set includes taps and dies along with correct tap and die wrenches, screwdriver for
die wrench, pitch gauge, thread-drill size chart INCLUDED SIZES
and durable plastic case
•Sizes listed below SIZE SIZE SIZE SIZE SIZE SIZE
NOTE: Not intended to be used with power tools. M3 x 0.5 M4 x 0.75 M6 x 0.75 M7 x 1.00 M10 x 1.25mm M12 x 1.75 INDEX
M3 x 0.6 M5 x 0.8 M6 x 1.00 M8 x 1.00 M10 x 1.50 1 /8” NPT
PART # 3801-0280 M4 x 0.7 M5 x 0.9 M7 x 0.75 M8 x 1.25 M12 x 1.5

All part numbers in BOLD MAGENTA 2017 PARTS EUROPE WATERCRAFT 181
are new this year.
