IGNITIONMATE DUO
SUNGLASSES
& GOGGLES •Lightning-fast ignition diagnostic tool that displays and compares the ignition
parameters of two cylinders or ignition systems simultaneously – on the same
engine or on two like engines
•The power sport industry’s top tool for trouble-shooting problems on all
ignition systems (transistor, CDI, magneto, points)
•Precise and sensitive in measurement, yet robust and weather resistant
ACCESSORIES •Designed to find the failed part or bad connection on the vehicle – the tool
pays for itself by virtue of the time saved in tracing the problem on the
vehicle before disassembly/ swapping out of parts
•Ignition signals are fast, high-voltage pulses of energy that can damage even
PROPULSION, a good digital multi-meter, whereas the IgnitionMate has been specially
designed to measure and dynamically display both primary and secondary
DRIVELINE ignition signals on bright LED bar graph displays
& HANDLING •Allows direct comparisons of secondary coil voltage, secondary spark current,
primary coil voltage/ current, ignition peak voltage pulses, in-cylinder spark
stability and intensity, or primary circuit voltages
•Dual low-tension leads and high-tension leads
ENGINE •The instrument is powered by an internal rechargeable 1.5Ah NiMH battery;
recharge the battery with any 12VDC source, such as a vehicle battery or
12VDC adapter 3807-0052
•Battery switches off after two minutes of no activity to conserve power
•Includes carrying case and necessary cable accessories
DESCRIPTION PART # DESCRIPTION PART #
GASKETS IgnitionMate Duo 3807-0052 Repl. backprobe set 3807-0079
& SEALS

FUEL/AIR
SYSTEMS
VACUUMMATE
PROFESSIONAL-GRADE ELECTRONIC
FOUR-CHANNEL THROTTLE BODY AND CARBURETOR SYNCHRONIZER
BODY
•The industry standard for fast and precise synchronizing of 2- and 4-stroke, two-, three- and four-cylinder engines
(synchronizes up to six cylinders with optional adapter)
•No fragile glass, no toxic mercury, no mechanical friction or inertia, no calibration hassles
•Solid-state medical-grade sensors are drop-proof, and self-calibrate for barometric pressure changes
•Shock- and water-resistant composite molded polyurethane and polycarbonate casing is strong and resilient
HANDLEBARS •Vertically arranged LED bars (40 LEDs in each bar) provide clear visuals (even in sunlight) of signals derived from
& CONTROLS solid-state electronic pressure sensors
•”RPM” mode for essential adjustment of engine speed before and after synchronizing – 2- or 4-stroke switch
allows correct readings on both engine types
•Flick the switch to check rpm on channel 1 and flick to VAC to display accurate vacuum readings
•”AVE” mode with three overlapping scale ranges 5-25, 20-40, 35-55 cm Hg for convenient and quick
ELECTRICAL synchronizing – precise 0.5 cm Hg resolution on all scales
•Diagnostic mode with auto-ranging scale for immediate visual check if engine is difficult to synchronize
•Quickly checks for non-sealing intake or exhaust valves, leaking manifold or a restricted air intake
•WS (workshop) model is powered by any 12V vehicle battery or 12VDC adapter; “Low input power” warning LED
•ME (marine) model has internal rechargeable 1.5Ah 7.2V NiMH batteries; recharge by connecting to a 12V vehicle battery or
12VDC adapter
LUBES •”Low battery” warning LED plus dual-purpose “Charge” LED that indicates external power connected and recharging in progress 3804-0020
•The kit includes soft nylon travel case, battery cord-set, T-connector and 4 x M5 & M6 flexi-rigid manifold connection adapters
DESCRIPTION PART # DESCRIPTION PART #
VacuumMate WS 3804-0020 VacuumMate ME (built-in battery) 3804-0021

TRANSPORT
& TRAILER

TOOLS 12V LED FLASHLIGHT
•Need emergency light while out for a ride, or you are not sure your vehicle charging
system is working right?
•Use the 6-LED flashlight, a reliable, powerful light source that checks battery status
and if the vehicle charging system is working correctly
MERCHANDISING •Works great in the workshop to light up those hard-to-see places
on your machine
•SAE connector for connection to an SAE battery charging cord
•40” L cable
PART # 3807-0182
