GENERAL, METRIC SERVICE/MAINTENANCE TOOLS

STREET
TIRES

PIVOT SUSPENSION VISE
DRAG/ •Designed to make suspension service simple and quick
V-TWIN TIRES •Holds shocks and forks securely while you change oil, re-valve, or change seals
•Pivoting head holds parts in any position, with mechanical stops every 45°
•Aluminum Soft Jaw Vise holds cylindrically shaped parts utilizing a 4 point grip system
•Large side holds 39 mm to 69 mm diameter parts
•Small side holds 14 mm to 39 mm diameter parts
•Steel frame is rigid yet has a small footprint, with four pre-drilled holes in the base for secure mounting to a bench
SCOOTER •Movable fluid catch pan with mesh insert, and threaded drain bung
TIRES •Soft Jaw Fork Peg holds fork slider up for removal of dust seal and seal retaining clip
•Repositionable bottom slide bar holds forks compressed while bleeding air (priming cartridge) during reassembly
and is an excellent platform for adding, adjusting and taking fork oil level measurements
•Can be used to assist in removing fork compression valve assembly (use of stock front axle required)
•Holds shock firmly around shock body, shaft or shock reservoir
OFFROAD •Facilitates removal of piston rod and seal head
TIRES •Facilitates removal of shock reservoir caps, chamber pistons or bladder DESCRIPTION PART #
•Holds shock to remove spherical bearings or needle bearings
•Holds shocks for removal of shock spring Pivot suspension vise 3805‑0148

ATV/UTV
TIRES &
WHEELS
FORK LEG HOLDER TOOL
•Holds fork legs and tubes for easy hands-free
TUBES & FORK TUBE TOOL servicing or rebuilding
ACCESSORIES •Mounts in vise to hold fork firmly during repair
•For use when assembling and disassembling without causing damage to fork assembly
the fork tube from the axle lugs •Will not scratch finish
DESCRIPTION PART # DESCRIPTION PART #
Fork tube tool 3805‑0045 Fork leg holder tool 3805‑0032
SHOP EQUIPMENT
& STANDS
SPLIT FORK
SEAL DRIVERS
GENERAL, •Available in 48 mm and 52 mm sizes
METRIC SERVICE/ •52 mm size is for fork seals like those
MAINTENANCE on Yamaha V-Max 09-10 3805‑0080 FORK SEAL DRIVERS
TOOLS DESCRIPTION PART # DESCRIPTION PART # •Split fork seal drivers save headaches
48 mm 3805‑0080 52 mm 3805‑0081 and seals TFSD35
•Fit both inverted and conventional forks
DESCRIPTION PART # DESCRIPTION PART #
DRAG/ 35 mm TFSD35 43 mm TFSD43
V-TWIN TOOLS 36-37 mm TFSD37 45-46 mm TFSD46
38-39 mm TFSD39 47-48 mm TFSD48
40-41 mm TFSD41 49-50 mm TFSD50
RINGER FORK
CHEMICALS & SEAL DRIVERS
LUBRICANTS •Innovative design makes tool
easier and more secure to use 3805‑0086
than old-fashioned pin-aligned drivers FORK SEAL
•Anodized aluminum locking ring features knurled finish
CLEANERS, for secure no-slip grip and positively locks body halves BULLET TOOLS
POLISHES & together during use •Protect the fork seal and wiper of inverted
PAINTS •No more worrying about part of the tool falling off and forks from damage by the bushing groove
damaging the fork leg or hitting your feet during installation
•Perfectly weighted to drive seals •Save time by eliminating the need to wrap the
•Body halves are machined from durable carbon steel and feature high- fork tube with tape
quality protective black e-coat with laser-engraved markings •Set includes 36, 41, 43, 45, 46, 47 and 48 mm bullet
TRANSPORT •Patent pending tools; also available separately MP08‑0272
& TRAILER DESCRIPTION PART # DESCRIPTION PART # •Each size is a different color
35-36 mm 3805‑0086 45 mm 3805‑0091 DESCRIPTION PART # DESCRIPTION PART #
37 mm 3805‑0087 46-47 mm 3805‑0092 Fork seal bullet set MP08‑0272 46 mm bullet MP08‑0277
39 mm 3805‑0088 48 mm 3805‑0093 36 mm bullet MP08‑0273 47 mm bullet MP08‑0278
41 mm 3805‑0089 49-50 mm 3805‑0094 43 mm bullet MP08‑0275 48 mm bullet 3805‑0001
MERCHANDISING 43 mm 3805‑0090 45 mm bullet MP08‑0276

SEALMATE™ FORK
SEAL CLEANER
•Easy way to keep your fork seals clean and debris free
INDEX •Extracts dirt and debris trapped between fork seal and tube
•Works on conventional and
upside-down forks DESCRIPTION PART #
•Sold each Sealmate™ 3805‑0143

368 All part numbers in BOLD MAGENTA are new this year.
