P. 822

GENERAL







                     OPTIMATE 4 DUAL PROGRAM
                     •OptiMate 4, the ultimate all-in-one tool for 12V battery care at home, now with
                      dual program that diagnoses, recovers, charges, tests and optimally maintains your
                      battery automatically
                     •Charge the battery directly or select the program to charge via the 12V port on
               TIRES &   your CAN-bus equipped bike
                TUBES  •With automatic keyless activation, OptiMate 4 Dual Program will charge and
                      maintain your battery automatically until it is disconnected
                     •Includes low voltage pulse recovery for even more effective recovery of badly
                      neglected, sulphated batteries; a user-friendly battery test at connection; a slick weatherproof
                      enclosure with built-in mounting lugs and improved energy efficiency
                     •Extending battery life by up to 400%, OptiMate 4 Dual Program will keep your battery safe and ready-
                      to-go for months on end
                     •Includes two detachable, interchangeable battery connectors: a connector with eyelets for
                      permanent connection and battery clips for bench charging
                     •Meets all relevant EN and IEC norms and CE directives  PART #        DESCRIPTION
                     •EU plug                                  3807-0227                   OptiMate 4 DP

                     OPTIMATE 3
                     DESULFATING/ MAINTAINING CHARGER                  3807-0253
                     •Smaller, lighter and more powerful than its predecessor
                     •Diagnoses, recovers, charges, checks and maintains batteries safely
                      for months
                     •Advanced, fully automatic battery charger and maintainer for all 12V
            CHEMICALS,  lead-acid batteries from 2,5 to 50A hours capacity
             HARDWARE •Recommended for sealed and conventional batteries for motorcycles
               & TOOLS  and similar vehicles, including dry-charged MF, sealed wet
                      maintenance-free types, AGM and sealed deep-cycle gel batteries
                     •Features vent-free enclosure, SAE weatherproof connectors and                           3807-0308
                      includes wall mounts
                     •Unique diagnostic function automatically identifies deeply discharged
                      (sulphated) batteries and applies a controlled high voltage with small
                      fixed current for a limited period to recover them
                     •Includes two detachable, interchangeable battery connectors:
                      a connector with eyelets for permanent connection and battery clips
                      for bench charging
                     •Comes with global input (100-240V)
                     •Meets all relevant EN and IEC norms and CE directives                                   3807-0309
                     •CE conformity                           PART #    DESCRIPTION  PART #  DESCRIPTION  PART #  DESCRIPTION
                     •EU plug                                 3807-0253  Single  3807-0308  2-bank   3807-0309  4-bank

                     OPTIMATE 1
                     •Fully automatic charger for 12V lead-acid batteries of all types from 2Ah to 50Ah capacity; long term
               LICENSE  maintenance up to 70Ah
                PLATE •Keeps battery at 100% charged when not in use
               FRAMES •Ideal for maintaining batteries of vehicles used seasonally or stored vehicles
                     •No risk of overcharging; safe for prolonged connection to the battery
                     •3,6 m long output cable
                     •Input current max: 0,30A at 110V-120V 50/ 60Hz
                     •Temperature range: from -20°C to 40°C (-4°F to 104°F)
                     •Includes PART #3807-0159 (O1) fused eyelet set and weather protected    PART #      DESCRIPTION
                      PART #3807-0165 (O4) clamps set for bench charging  3807-0282                       AccuMate Compact

                     OPTIMATE 2
                     •The OptiMate 2 smart charger-maintainer is the most cost-
                      effective solution for long-term maintenance of a 12V battery
                      in any vehicle that is stored in or outdoors
                     •Weatherproof and very easy to use; simply connect to the
                      battery and plug it into the nearest power socket; the rest is
                      fully automatic
                     •With 0,8A constant current OptiMate 2 automatically brings the
                      battery to full charge and then switches to the unique OptiMate
                      battery-saving maintenance charge mode to keep the battery
                      at 100% ready and at the same time provides power to the on-board computer,
            WINDSHIELDS
                      display or anti-theft alarm
                     •Recommended for STD (with removable filler caps), sealed AGM (absorbed glass mat)
                      and sealed GEL 12V lead-acid batteries up to 50Ah
                     •Weighing in at 1 lb including cables and accepting any AC supply between 100-240VAC,
                      OptiMate 2 is a true world traveler
                     •Includes permanent ringlet connector with weatherproof cap and a set of battery clips
                     •Fully automatic operation that includes all safety features such
                      as reverse polarity protection, no spark connection: approved to
                      UL and CSA safety standards for automatic battery chargers  PART #  DESCRIPTION  PART #  DESCRIPTION
                     •CE conformity                                   3807-0126      EU plug   3807-0127      UK plug


                820                                  ALL PART NUMBERS IN BLUE ARE NEW
