GENERAL

VOLTAGE 3807-0247
TESTER
•Find out which line
does not work with
this clever tool
•Small and able to reach
those hard-to-reach spots
•Works with 6V and 12V
electrical systems
•Sold each; replacement bulbs sold in packs of 10 3807-0248 TIRES &
TUBES
PART # DESCRIPTION ONBOARD DIAGNOSTIC
3807‑0247 Voltage tester 6V/ 12V VOLTMETER
3807‑0248 Replacement bulb for voltage tester •Charging system failure can be more than
an inconvenience, so it’s important to take
IGNITION SYSTEM TESTER preventative measures
®
•Test the integrity and strength of an •JIMS new Onboard Diagnostic Voltmeter attaches easily to the
ignition system battery to quickly spot potential charging system and
•Spark gap is adjustable from 0-10 mm – the larger battery problems
the gap the spark will jump, the stronger the •Works with all 6V or 12V batteries and charging systems
ignition system PART # DESCRIPTION
•Will test the ignition systems of most motorcycles, 3807‑0345 Onboard diagnostic volt meter
watercraft, ATVs and snowmobiles
PART # DESCRIPTION
MP08‑122 Ignition system tester

IN-LINE IGNITION TIMING TESTER
SPARK •Precisely times point-type ignitions
TESTER •A switch allows for either a light or a tone at the CHEMICALS,
precise time of point closure
•Supplies a quick, •Can also be used as a continuity tester HARDWARE
easy visual check of ignition system & TOOLS
•Works on all ignitions systems, including distributorless ignitions PART # DESCRIPTION
Timing tester
LM4100
•Made in the U.S.A.

PART # DESCRIPTION REMOTE
3804‑0033 In-line spark tester START

CAT III DIGITAL BUTTON
MULTIMETER •Activates starter
and rotates engine without starting
•19 functions and 7 ranges •Handy for tappet adjustments, servicing
•Manual ranging and diagnosing starting and electrical issues
•Protective rubber boot •Includes 4’ lead cable with alligator clip for start positive post terminal
•600V DC, 600V AC, 10A DC, 10A AC and motor post negative hookups
with 20 M resistance
•Continuity buzzer •Made in the U.S.A.
•Diode test PART # DESCRIPTION
•Battery test 3804‑0034 Remote start button
•Data hold MULTIMETER
•Auto power shut-off LICENSE
•Fuse protected VOLT PROBE KIT PLATE
•CAT III 600V ETL approval •Assortment of color FRAMES
PART # DESCRIPTION coded, sharp probes
3807‑0223 CAT III digital multimeter for precise and non-damaging diagnostics
•Standard 4 mm banana plug connections
work with most multimeters leads
•180°, 45°, 90° probes for hard-to-reach
terminals as well as standard alligator clips
•All probes are fully insulated with 30 volt protection
•Made in the U.S.A.
PART# DESCRIPTION
FEELER GAUGES 3807‑0224 Multimeter probe kit

•For ignition and general purpose measuring 26-BLADE
1
•Blades measure: 3” x /2” with thickness 3801-0248 OFFSET
•Made of tempered 1095 spring steel FEELER GAUGE
1
•PART #3801-0247 contains thirty-two 3” x /2” blades with thicknesses: 1
0,0015; 0,002; 0,0025; 0,003; 0,004; 0,005; 0,006; 0,007; 0,008; 0,009; 0,010; •Contains twenty-six 4” x /2” with
0,011; 0,012; 0,013; 0,014; 0,015; 0,016; 0,017; 0,018; 0,019; 0,020; 0,021; thicknesses: 0,005; 0,006; 0,007; 0,008; 0,009;
0,022; 0,023; 0,024; 0,025; 0,026; 0,028; 0,030; 0,032; 0,035 and 0,010 brass 0,010; 0,011; 0,012; 0,013; 0,014; 0,015; 0,016; 0,017; 0,018; 0,019; 0,020;
blade for transistorized engines 0,021; 0,022; 0,023; 0,024; 0,025; 0,026; 0,027; 0,028; 0,029 and 0,030 WINDSHIELDS
•PART #3801-0248 contains twenty-six 3” x /2” blades with thicknesses: •Made of tempered 1095 spring steel
1
0,0015; 0,002; 0,0025; 0,003; 0,004; 0,005; 0,006; 0,007; 0,008; 0,009; 0,010; •Equipped with knurled lock-nut, which releases the blades instantly
0,011; 0,012; 0,013; 0,014; 0,015; 0,016; 0,017; 0,018; 0,019; 0,020; 0,021; for rapid selection of size desired and when tightened locks the
0,022; 0,023; 0,024 and 0,025 individual blade onto the working position, retaining the blades not in
•The sizes, both decimal and metric equivalent, are permanently use firmly to handle
etched on each blade •4” long blades have 1” 45° offset for checking valve clearances
•Made in the U.S.A. •The sizes, both decimal and metric equivalent,
are permanently etched on
PART # DESCRIPTION PART # DESCRIPTION each blade PART # DESCRIPTION
3801‑0247 32-Blade feeler gauge 3801‑0248 26-Blade feeler gauge •Made in the U.S.A. 3801‑0249 26-Blade offset feeler gauge
