IRONHEAD XL

SEATS &
SISSY BARS

EXHAUST

CARBURETORS CHROME MOTOR BOLT SETS
& AIR FILTERS •Chrome socket‑head bolt set, available in
either knurled or smooth polished head styles
•Sets contain socket‑head bolts for cam, primary,
generator, sprocket, rocker box, top motor
ENGINE mount, lifter base, point or magneto cover
•Made in the U.S.A.
FITMENT KNURLED PART # SMOOTH PART # FITMENT KNURLED PART # SMOOTH PART #
For 77‑E84 XL DS‑190760 DS‑190760S For 71‑76 XL DS‑190761 DS‑190761S

TRANSMISSION
& DRIVELINE

GASKETS
& SEALS

ELECTRICAL
& LIGHTING

HANDLEBARS, INDIVIDUAL CHROME SOCKET-HEAD BOLT SETS
CONTROLS & •Socket‑head bolt sets to meet virtually any custom need
MIRRORS
•Available in knurled or smooth head style
•Made in the U.S.A.
DESCRIPTION FITMENT KNURLED PART # SMOOTH PART #
CABLES S&S Super‑B air cleaner and carb 57‑85 XL DS‑190795 ‑
Disc brake caliper mount, front (dual disc) 77‑83 XL DS‑190706 ‑
Front fork drain 76‑85 XL DS‑190713 1 ‑
Generator 71‑85 XL DS‑190787 ‑
Handlebar clamp (not pullbacks) 1 1 /4” long 74‑85 XL DS‑190717 DS‑190717S
BRAKES Handlebar lever mount and master cylinder cover 73‑81 XL DS‑190719 ‑
Handlebar lever mount and master cylinder cover 82‑85 XL DS‑190720 ‑
License plate mount 57‑85 XL DS‑190726 ‑
Point cover (button head) 79‑85 XL DS‑190871 ‑
OIL TANKS, Point cover (button head) 70‑78 XL DS‑190872 ‑
FILTERS & Rocker box set 71‑76 XL DS‑190994 ‑
GAS TANKS Triple tree pinch bolts 57‑85 XL DS‑190743 ‑
1 Sold in pairs; include Allen wrench.

DASHES
& GAUGES

CHASSIS,
SUSPENSION,
FENDERS
& WHEELS
CHROME SOCKET-HEAD
FLOORBOARDS CAM/ PRIMARY COVER
& PEGS
BOLT SETS
•Available in knurled or smooth
polished head style
•Provide a custom finish
HARDWARE •Made in the U.S.A.
DESCRIPTION FITMENT KNURLED PART # SMOOTH PART #
Cam, primary, sprocket cover and oil check screw 77‑85 XL DS‑190750 DS‑190750S
Primary cover set only 77‑85 XL ‑ DS‑190392S
Cam, primary and oil check screw 71‑76 XL DS‑190751 DS‑190751S
GENERAL Primary cover set only 71‑76 XL ‑ DS‑190391S
Cam and primary side covers w/ special tapered heads and oil fill check screw 67‑70 XLH; 70 XLCH DS‑190753 ‑
Cam and primary covers w/ special tapered head and oil fill check screw 57‑69 XLCH DS‑190752 ‑
750 ALL PART NUMBERS IN BLUE ARE NEW
