IRONHEAD XL

1620‑0395
SEATS & DS‑243512 1620‑0399
SISSY BARS

FOOTPEGS AND
EXHAUST SHIFTER PEGS
•Available in wide band
or full rubber styles
•Footpegs sold in pairs;
shifter pegs are sold each
CARBURETORS •Available with chrome or black‑anodized finish
& AIR FILTERS •Made in the U.S.A. with domestic materials DS‑253032
PART # DESCRIPTION PART # DESCRIPTION
MALE‑MOUNT PEGS SHIFTER PEGS
DS‑243512 1” wide band; chrome DS‑253032 Wide band; chrome
ENGINE 1620‑0395 1” wide band; black
1620‑0399 1” full rubber; black

TRANSMISSION
& DRIVELINE REPLACEMENT PEG
RUBBERS FOR
JAYBRAKE FOOTPEGS
GASKETS •Replacement peg rubbers for 1” wide band pegs SHIFT PEG EXTENDER
& SEALS •Sold for two pegs •Wide gas tanks create a problem, especially for short‑inseam
PART # DESCRIPTION riders; this shift peg extender is just what is needed
DS‑243518 1” wide band pegs •Extends the shift peg out 1,5”
•Manufactured from billet stainless steel and highly polished
ELECTRICAL •Made in the U.S.A.
& LIGHTING PART # DESCRIPTION
1603‑0146 For 65‑85 XL

HANDLEBARS,
CONTROLS &
MIRRORS

1620‑1221 1620‑1222
CABLES
EARLY-STYLE FOOTPEG
MOUNT ADAPTERS FOOTPEG SPRING WASHERS
BRAKES •Adapters convert old‑style male footpeg mounts •Used for creating friction on male‑mount footpegs
that accepted female‑style pegs to the late‑style •Can be used on most aftermarket male‑mount footpegs
female mounts that accept male‑mount pegs •Sold each to consumer; sold to dealer in 10‑pack
•Allow the use of male‑mount footpegs on earlier model motorcycles
OIL TANKS, •Sold in pairs PART # DESCRIPTION
FILTERS & •Made in the U.S.A. DS‑253005 For 57‑85 XL; repl. OEM #50912‑72
GAS TANKS
PART # DESCRIPTION PART # DESCRIPTION
1620‑1221 Chrome 1620‑1222 Black

DASHES CHROME FOOTPEG SHORT MAGNUM PEG MOUNTS
& GAUGES MOUNTING PINS •Accept all standard male mount pegs
1
•Chrome‑plated hardened steel • /2”‑13 threads
•Sold in pairs
CHASSIS, •Pins are held in place by retaining clips PART # DESCRIPTION
3
SUSPENSION, •Eliminate /8” bolts held in place by retaining ring DS‑253596 For 57‑85 XL
15
FENDERS •For /16” wide peg mounts
& WHEELS •Sold each to consumer; sold to dealers in 10‑pack
PART # DESCRIPTION
1904‑5041 For 57‑85 XL
FLOORBOARDS DS‑253483
& PEGS
REPLACEMENT CHROME CHROME PASSENGER
HARDWARE FOOTPEG MOUNTS FOOTPEG MOUNT KIT
•Make it possible to mount Drag Specialties •Used for mounting passenger
or OEM footpegs in any location footpegs or replacing existing OEM footpeg mounts
•Chrome‑plated steel construction DS‑253492 •Includes mounting hardware
PART # DESCRIPTION •Accepts most male mount pegs
GENERAL DS‑253483 Footpeg clevis mount with /2”‑20 thread •Sold in pairs
1
(ea.); repl. OEM #50900‑72 PART # DESCRIPTION
DS‑253492 Footpeg clevis mount with 3 /8”‑24 thread (pr.) DS‑252990 For 83‑85 XL; repl. OEM #50610‑86T

748 ALL PART NUMBERS IN BLUE ARE NEW
