UTILITY VEHICLE

FULL FOLDING WINDSHIELDS
Premium .177” thick clear polycarbonate shield. Centrally hinged for ventilation.
Tool-less operation. Stainless steel rubber coated mount straps. Rubber seal helps
keep elements out. Replacement kit (Part # 2317-0164) with 6" rubber seal available
separately. Made in the USA.

REPL.
FULL RUBBER REPL.
FOLDING OVERALL OVERALL STRAPS HARDWARE
FITS MODEL PART # WIDTH HEIGHT PART # PART #
ARCTIC CAT
PROWLERS 11-12 (ROUND TUBING) 2317-0180 135 CM (53.13") 77,5 CM (30.51") 2317-0258 2317-0260
WILDCAT TRAIL 13-15 2317-0296 119 CM (46.96") 52 CM (20.56") 2317-0258 2317-0260
CAN-AM
COMMANDER (ALL) 11-17 2317-0181 132 CM (52.05") 81 CM (32.02") 2317-0258 2317-0259
MAVERICK 1000 14-17 2317-0300 132 CM (52.18") 66 CM (26.00") 2317-0258 2317-0259
DEFENDER 16-17 2317-0360 130 CM (51.37") 83 CM (32.75") 2317-0258 2317-0259
CF MOTO
U FORCE-ALL 2317-0329 125 CM (49.19") 58, 7 CM (23.11") 2317-0258 2317-0260
Z FORCE-ALL 2317-0330 106 CM (41.87") 57 CM (22.57") 2317-0258 2317-0260
HONDA
BIG RED 09-14 2317-0182 150 CM (59.25") 56,4 CM (22.23") 2317-0258 2317-0260
1
PIONEER 500 15-17 2317-0297 109 CM (42.94") 73,7 CM (28.87") 2317-0258 2317-0260
PIONEER 700 / 700-4 14-17 2317-0178 120 CM (47.49") 63 CM (24.85") 2317-0258 2317-0260
PIONEER 1000 / 5 15-17 2317-0356 136 CM (53.50") 64,8 CM (25.53") 2317-0258 2317-0260
KAWASAKI
2
MULE 3010 00-08 2317-0183 137 CM (54.00") 90,5 CM (35.62") 2317-0258 2317-0260
MULE 4010 09-17 2317-0184 2 134 CM (53.00") 78,5 CM (30.91") 2317-0258 2317-0260
TERYX 750 10-13 2317-0185 122 CM (48.00") 67,8 CM (26.68") 2317-0258 2317-0260
TERYX 800 14-15 2317-0186 139 CM (54.94") 68,4 CM (26.93") 2317-0258 2317-0260
TERYX 800 16-17 2317-0357 140 CM (55.23") 56,6 CM (22.27") 2317-0258 2317-0260
TERYX 4 12-15 2317-0186 139 CM (54.94") 68,4 CM (26.93") 2317-0258 2317-0260
TERYX 4 16-17 2317-0357 140 CM (55.23") 56,6 CM (22.27") 2317-0258 2317-0260
MULE PRO-FXT 15-17 2317-0298 148 CM (58.25") 77,6 CM (30.56") 2317-0258 2317-0260
KYMCO
XUV 500 / 700 ALL 2317-0301 137 CM (54.00") 62,4 CM (24.56") 2317-0258 2317-0260
POLARIS
RANGER 400 (MID SIZE) 14 2317-0189 120 CM (47.12") 74,8 CM (29.44") 2317-0258 2317-0260
RANGER 400/500 ALL MODELS
(MID SIZE) 09-14 2317-0189 120 CM (47.12") 74,8 CM (29.44") 2317-0258 2317-0260
RANGER 500 00-08 2317-0187 149 CM (58.75") 86,2 CM (33.93") 2317-0258 2317-0260
