www.partseurope.eu PROPULSION, DRIVELINE & HANDLING

VTS/ AUTO DROP NOZZLE KITS
FOR YAMAHA APPAREL
•The first manually activated VTS nozzle with Auto Drop functions
•When riding with the VTS adjusted in neutral position the nozzle will drop 5° in the turns
allowing for a much smoother high-speed turn to be made
•When the steering reaches the straight position the nozzle returns back to the straight position
•When riding with a full tank, the best VTS setting is usually in the one click up position and SUNGLASSES
stays there & GOGGLES
•With the R&D VTS Nozzle kit you can ride one click up (5° up) and when you turn the nozzle will
drop 5° which is back to zero or straight position
•When the steering returns to straight, the nozzle resumes the one click up (5° up) position
•The kit comes preset and it’s amazingly easy to install 4809-0278
•The ball-burnished polished finish will add a racing look to your river racer ACCESSORIES
FITS MODEL PART # FITS MODEL PART #
GP 1200R 4809-0278 GP 1300R 4809-0279

VTS QUICK SHIFT CAM KIT PROPULSION,
FOR YAMAHA FZR, FX HO, SHO, SVHO-FX DRIVELINE
•The R&D FZR VTS Trim Driver Cam is a cam device that installs directly in place of & HANDLING
the OEM plastic VTS trim driver cam
•The R&D cam is designed to recalibrate the trim position amount from an OEM 7 to 8° per shift to a finer and
speed-friendly 4° per shift
•The OEM neutral position setting is 85° or 5° up from horizontal zero ENGINE
•The new recalibrated position with the R&D Trim Cam is 87.5° or 2.5° up from horizontal zero
•The R&D Trim Cam will deliver a more positive group of adjustments that will allow much better turning capabilities,
as well as finer adjustments for rough water conditions
•The R&D Trim Cam will work with the OEM trim nozzle assembly, PART # 4809-0280
or the R&D Auto Trim Kit
GASKETS
& SEALS

TRIM ROD/ STEERING CABLE BALL JOINTS FUEL/AIR
4807-0047 4807-0049
•Replace OEM ball joint SYSTEMS
FITS MODEL OEM # PART #
STEERING CABLE BALL JOINT
Sea-Doo 99-11 (all) 277000775 4807-0047 1
Sea-Doo 92-01 (all) 277000153/ 277000037 4807-0049 2
Sea-Doo 97-03 (all) 277000646 4807-0050 3 BODY
TRIM ROD BALL JOINT
Sea-Doo 951 GSX models 98-99 277000918 4807-0048
Sea-Doo 951 XP models 98-02 277000918 4807-0048
1
1 Fits the rear of all steering cables /4”-28 UNF threads (later/ larger). HANDLEBARS
2 Fits the rear of all steering cables OEM #10-32 UNF threads (early/ smaller). & CONTROLS
3 Front small thread.
2.5 DEGREE NOZZLE WEDGE KIT
FOR SEA-DOO
•Designed, developed and tested extensively in all types of flat ELECTRICAL
and rough water conditions to ensure that there would be no compromises
anywhere in the handling performance
•Most brands of watercraft have some form of V.T.S. (variable trim system) including
other model Sea-Doos; why the 951 and RXT don’t have a trim system is a mystery –
it’s about the only feature that this model is missing
•Extensive testing has led our development team to wedge the reduction nozzle LUBES
up 2.5 degrees which will inexpensively give your machine better handling
everywhere and provide a boost of 1 to 2 mph in top-speed performance)
•The billet aluminum CNC machined 2.5 degree reduction nozzle wedge kit
was designed to work with the OEM O.P.A.S. system and installs easily in 15 to 4809-0267 4809-0268
20 minutes with R&D’s “easy install” directions TRANSPORT
FITS MODEL PART # FITS MODEL PART # & TRAILER
951 4809-0267 RXT 4809-0268

TOOLS

1° NOZZLE WEDGE KIT 4809-0116 4809-0200
FOR KAWASAKI ULTRA 250/ 300
•Inexpensive way to boost acceleration, handling and top-speed performance MERCHANDISING
•Constructed of CNC-machined billet aluminum
•Causes bow to ride slightly higher which vastly reduces bow spray
•Will not affect reverse gate operation
•Includes all necessary hardware and instructions
FITS MODEL PART # FITS MODEL PART # INDEX
KAWASAKI KAWASAKI (CONT)
Ultra 250 4809-0116 Ultra 300 4809-0200

All part numbers in BOLD MAGENTA 2017 PARTS EUROPE WATERCRAFT 49
are new this year.
