GENERAL

TIRES & PARTS EUROPE INNER TUBES
TUBES •Manufactured to the highest quality as approved by all the Japanese motorcycle manufacturers
•Each tube is individually boxed with a full range of sizes and valve stem types clearly marked on each box end
•”Real butyl tubes” made from 100% butyl polymer, unlike other “butyl” tubes, which are blended with butyl polymer and natural rubber
•100% butyl tube minimizes natural air leakage while maintaining air pressure for a longer period of time
FITS RIM SIZE FITS TIRE SIZE STEM TYPE PART # FITS RIM SIZE FITS TIRE SIZE STEM TYPE PART #
16” 5.00, 5.10 TR‑15 0350‑0326 19” 110/90 TR‑4 0350‑0348
16” 5.10 TR‑4 0350‑0334 19” 120/80 TR‑4 0350‑0348
16” 130/90 TR‑4 0350‑0334 21” 2.50 TR‑4 0350‑0349
19” 2.75, 3.60 TR‑4 0350‑0346 21” 2.75, 3.00 TR‑4 0350‑0350
19” 90/90 TR‑4 0350‑0346 21” 90/90 TR‑4 0350‑0350
19” 3.25, 4.10 TR‑4 0350‑0347 21” 80/ 100 TR‑4 0350‑0350
19” 100/90 TR‑4 0350‑0347 21” 90/ 100 TR‑4 0350‑0350
19” 110/80 TR‑4 0350‑0347 21” 100/80 TR‑4 0350‑0350
19” 4.00, 4.50 TR‑4 0350‑0348

CHEMICALS,
HARDWARE
& TOOLS

DRAG SPECIALTIES INNER TUBES
•High‑quality rubber inner tubes
•Custom sizes for extra‑wide wheel applications
•Sold each
•Do not use on rim types CP or MT H2
LICENSE RIM SIZE FITS TIRE SIZE VALVE STEM TYPE PART #
PLATE 16” 5.00‑5.10”; 130/90 SRV DS181226
FRAMES 16” 5.00‑5.10”; 130/90 SMV DS181227
16” 5.00‑5.10”; 130/90 CMV DS181232
16” 130/90, 140/90, MT90, MU85 SRV 0350‑0173
16” 130/90, 140/90, MT90, MU85 SMV 0350‑0174
16” 130/90, 140/90, MT90, MU85 CMV 0350‑0175
16” 6.00”; 150/80; MV SMV 0350‑0115
16” 6.00”; 150/80; MV CMV 0350‑0116
16” 180/65 CMV 0350‑0117
18” 3.50‑4.00”; 100/90; 110/90; MM; MN/MP CMV DS181222
18” 4.00‑4.50”; 110; 120; MR CMV DS181223
19” 2.75‑3.00”; 80/90; MH CMV DS181229
19” 3.25‑3.50”; 90/90; 100/90; MJ; MM CMV (0,45” stem diameter) DS181230
21” 2.75‑3.00”; 80/90; MH CMV DS181224
21” 3.25‑3.50”; 90/90; 100/90; MJ; MM CMV DS181225

INNER TUBES
•Michelin Airstop tubes are used by those who want the very best
•Features an overlap splice that is stronger than the butt splice used in most others
•Splice is always placed opposite the valve, which helps to provide a more balanced tube
WINDSHIELDS
RIM SIZE FITS TIRE SIZE(S) STEM TYPE PART #
16” 3.25, 3.50, 100/80, 90/90, 100/90 TR 4 0350‑0125
16” 120/80, 110/90 TR 4 0350‑0126
16” MU85, MU90, MT90, 150/80, 160/80, 120/90, 130/90, 140/90 Short 90° 0350‑0080
16” MU85, MU90, MT90, 150/80, 160/80, 120/90, 130/90, 140/90 TR 4 0350‑0141
19” 2.50, 3.00, 90/90 TR 4 0350‑0137
19” 3.25, 120/60, 110/80, 100/90, 110/90, 90/ 100 TR 4 0350‑0138
21” 2.50, 2.75, 3.00, MH90, 80/90, 90/90, 80/ 100, 90/ 100 TR 4 0350‑0139

SAFETY WARNING: For information on tire care, safety, maintenance, mounting, manufacturer’s warranty and other
information consult tire manufacturer’s publication(s) and/or website(s) for complete tire information.
762 ALL PART NUMBERS IN BLUE ARE NEW
