GENERAL

TIRES &
TUBES

SAFETY MILEAGE MARK II AM7
•Provides excellent handling and a smooth ride
•Perfect mate to Speedmaster front rib
CHEMICALS, •Can be used on sidecars
HARDWARE •Tube type
& TOOLS •S‑rated for speeds up to 180 km/h (112 mph) AV004 AV005
SIZE LOAD/ SPEED INDEX TL/TT PART # RECOMMENDED TUBE (PARTS EUROPE) RECOMMENDED TUBE (HEIDENAU)
5.00 ‑ 16 69S TT AV004 0350‑0334 (CMV TR‑4) 0350‑0242 (CMV), 0350‑0243 (SMV), 0350‑0243 (SRV)
4.00 ‑ 18 64S TT AV005 0350‑0344 (CMV TR‑4) 0350‑0260 (CMV)
3.50 ‑ 19 57S TT AV‑400 0350‑0347 (CMV TR‑4) 0350‑0266

LICENSE
PLATE
FRAMES

AM20/ AM21 CRUISER/ TOURING
•All‑weather tire made of 4‑ply nylon for long wear
•Designed for the cruising or touring rider
•Specially designed tread rubber compound allows for superior wet
grip and improved braking and handling
•H‑rated for speeds up to 210 km/h (130 mph) AM20 Front AM21 Rear
RECOMMENDED TUBE
SIZE LOAD/ SPEED INDEX TL/TT PART # (PARTS EUROPE) RECOMMENDED TUBE (HEIDENAU)
AM20 FRONT
130/90 ‑ 16 73H TL AV‑086 0350‑0334 (CMV TR‑4) 0350‑0242 (CMV), 0350‑0243 (SMV), 0350‑0243 (SRV)
90/90 ‑ 19 52H TL AV026 0350‑0346 (CMV TR‑4) 0350‑0266 (CMV)
90/90 ‑ 21 (not recommended for FXSTS) 54H TL AV029 0350‑0350 (CMV TR‑4) 0350‑0270
AM21 REAR
MT90 ‑ 16 (reinforced) 74H TL AV040 0350‑0334 (CMV TR‑4) 0350‑0242 (CMV), 0350‑0243 (SMV), 0350‑0243 (SRV)
WINDSHIELDS
SIZE LOAD/ SPEED INDEX TL/TT PART # RECOMMENDED TUBE PART # ANGLED
AM20 FRONT
130/90 ‑ 16 73H TL AV‑086 0350‑0218 0350‑0080
90/90 ‑ 19 52H TL AV026 0350‑0219 ‑
90/90 ‑ 21 (not recommended for FXSTS) 54H TL AV029 0350‑0220 ‑
AM21 REAR
MT90 ‑ 16 (reinforced) 74H TL AV040 0350‑0221 0350‑0080

SAFETY WARNING: For information on tire care, safety, maintenance, mounting, manufacturer’s warranty and other
information consult tire manufacturer’s publication(s) and/or website(s) for complete tire information.
756 ALL PART NUMBERS IN BLUE ARE NEW
