IMPLEMENTS & TOWING

FLATBED TRAILER UTILITY TRAILER
Designed to be towed behind an ATV. Expanded metal flatbed (86 cm x 122 cm) 18-gauge steel construction. 280 L (10 cubic feet) capacity trailer has 450 kg
with a 16-gauge steel frame. 453 kg (1000 lb.) load capacity. weight limit. Oil lube roller bearings grease fittings for easy lubrication.
Deck tilts to dump load by removing one cotter pin. 46 cm (18") ATV wheels with roller bearings 4.00 x 8 pneumatic tires. Features removable tailgate, dump bed. Hitch pin
2,5 cm (1") steel axle. Black powder-coat finish resists rust. Hitch pin included. included. Made in USA. Body measures: 76 cm L x 122 cm W x 30,5 cm H
(30" x 48" x 12"). Wheels: 16 x 6.5 x 8
DESCRIPTION PART # DESCRIPTION PART #
FLATBED TRAILER 4504-0125 UTILITY TRAILER M92-21041

BALL HITCH CONVERSION KIT
Converts Utility Trailer part # M92-21041 from pin hitch to a ball hitch (for other brands drilling
may be required). Powder coated steel connector bracket with galvanized steel coupler.
Comes complete with necessary hardware to bolt to cart drawbar. Fits 48 mm (1-7/8") trailer
ball (coupler included). Made in the USA.
DESCRIPTION PART #
BALL HITCH CONVERSION KIT 4504-0036

SWIVEL DUMP TRAILER
354 Liter (12.5 cubic feet) heaped capacity .565 kg (1,250 lb) load capacity.
Structural foam cart body will not rust. Pass-through undercarriage provides a full
30,5 cm (12") of ground clearance.Pivoting hitch allows cart to adjust to uneven terrain.
Full 60° dump angle .Cart body swivels to easily dump load anywhere within a 100° radius.
Works with a 48 mm (1 7/8") ball. Foot pedal activates dump mechanism ATV/UTV/Tractor
compatible. Tires – 41 cm x 19 cm x 20 cm (16" x 7.5" x 8").
Overall length – 194 cm (L) x 120 cm (W) x 80 cm (H) (76.26" x 46.77 x 31.12")
Box length – 122 cm (L) x 102 cm (W) x 37 cm (H) (48" x 40" x 14.5") TUB SLED & TOW BAR
Assembly required. Made in U.S.A. Molded and measures 142 cm (56") L x 66 cm (26")W x 24 cm (9.5") H.
Add the tow bar to tow behind your snowmobile or ATV/UTV.
DESCRIPTION PART # Ribbed bottom excellent for tracking. Tow bar sold separately.
SWIVEL DUMP TRAILER 4504-0099 Made in the USA.
WHEEL REPLACEMENT 4504-0119
SPARE SPACER 4504-0120 DESCRIPTION PART #
SPARE WASHER 4504-0121 TUB 4503-0070
TOW BAR 4503-0071
68
