SUSPENSION & DRIVE

LEFT AXLE RIGHT AXLE
FITS MODEL PART # PART #
COMPLETE REAR AXLE ASSEMBLIES (CON’T)
POLARIS (CON’T)
570 SPORTSMAN (ALL) 15-16 0214-1196 0214-1196
600 SPORTSMAN 03-05 0214-1062 0214-1062
700 RANGER R09WH68AC/AG/AH/AL/AR/AZ CREW 09 0214-1081 0214-1082
700 RANGER R09HH68/HY68 (ALL EXCEPT CREW AND 6X6) 09 0214-1081 0214-1082
700 RANGER R08WH68AG/AH/AK/AR CREW 08 0214-1093 0214-1094
700 RANGER R08RH68 EFI/XP (ALL OPTIONS) 08 0214-1093 0214-1094
700 RANGER LE R07RH68AD/G/H/K/L/O/P/W (MFG. BEFORE 8/28/06) 07 0214-1101 0214-1102 HEAVY DUTY AXLES
700 RANGER LE R07RH68AD/G/H/K/L/O/P/W (MFG. AFTER 8/28/06) 07 0214-1093 0214-1094 W/ VOODOO AXLE TECHNOLOGY
700 RANGER XP 05-06 0214-1101 0214-1102 For ultimate axle strength and articulation. Our revolutionary design provides ultra-high
700 SPORTSMAN 06-07 0214-1095 0214-1095 strength and the ability to operate at angles other can’t. Increased range of motion. Utilizes
700 SPORTSMAN 03-05 0214-1062 0214-1062 a slip spline that allows the axle to compress and extend 50 mm (2"). Telescoping axle bars
700 SPORTSMAN X2 08 0214-1096 0214-1096 are carried on linear motion ball bearings for smooth action that won’t bind under load.
800 RANGER R13RH76AG/AH/AN EFI MIDSIZE 13-14 0214-1090 0214-1090 Increased operating angle inner CV joints that allow 45° of articulation, while a slip spline in
800 RANGER R10HR76AG/AR EFI 6X6 10-16 0214-1081 0214-1082 the axle shaft provides 50 mm (2”) of travel. Ideal for ATVs and UTVs with lift kits or extended
800 RANGER R10TH76TY EFI 10-12 0214-1084 0214-1084 A-arms. Made in the USA.
800 RANGER EFI CREW 10-13 0214-1084 0214-1084
800 RZR 08-14 0214-1098 0214-1098 LEFT HAND RIGHT HAND
800 RZR S/4 09-14 0214-1086 0214-1086 FITS MODEL AXLE PART # AXLE PART #
800 SPORTSMAN 11-14 0214-1083 0214-1083 FRONT HEAVY DUTY AXLES
800 SPORTSMAN A10CL76AA 6X6 10 0214-1095 0214-1095 ARCTIC CAT
800 SPORTSMAN A10MN76AX/AZ 10 0214-1095 0214-1095 PROWLER 550/650 06-14 4X4 0214-0762 -
800 SPORTSMAN A09CL76AA 6X6 09 0214-1095 0214-1095 PROWLER 700 08-14 4X4/XTX 0214-0762 -
800 SPORTSMAN A09MN76AX/AZ 09 0214-1095 0214-1095 PROWLER 700 11-15 4X4 HDX - 0214-0762
800 SPORTSMAN A09DN76AB/AL/AY 09 0214-1096 0214-1096 PROWLER 1000 09-14 4X4 - 0214-0762
800 SPORTSMAN A09DN76FC INTL 09 0214-1096 0214-1096 CAN-AM
800 SPORTSMAN A08DN76AF/AG/AH/AL/AJ/AS TOURING 08 0214-1096 0214-1096 COMMANDER 800/1000 11-16 4X4 0214-0770 0214-0769
800 SPORTSMAN A08DN76FC INTL 08 0214-1096 0214-1096 MAVERICK 14-16 XC (60” WIDE MODELS) 0214-0770 0214-0769
800 SPORTSMAN A07MN76AF/AT/AY 06-07 0214-1095 0214-1095 KAWASAKI
800 SPORTSMAN A05MH76AC/AT/AU/AW 05 0214-1062 0214-1062 BRUTE FORCE 650I/750I 05-13 4X4 0214-0743 0214-0744
800 SPORTSMAN HO 08-09 0214-1095 0214-1095 TERYX 750 08-13 4X4- EXC. TERYX4 0214-0767 0214-0767
800 SPORTSMAN X2 08-09 0214-1096 0214-1096 POLARIS
800 SPORTSMAN X2 A07TH76AU (MFG. BEFORE 7/25/07) 0214-1092 0214-1092 RANGER 900 4X4-EXC DIESEL 13-14 0214-0755 0214-0755
850 SCRAMBLER 13-14 0214-1089 0214-1089 RZR 570 4X4 12-14 0214-0740 0214-0740
850 SPORTSMAN 10-15 0214-1089 0214-1089 RZR 800 4X4 08 0214-0740 0214-0740
850 SPORTSMAN 09 0214-1091 0214-1091 RZR 800 4X4-EXC. S SERIES 09-10 0214-0740 0214-0740
850 SPORTSMAN HO 13-14 0214-1089 0214-1089 RZR 800 4X4-S SERIES 09-10 0214-0755 0214-0755
900 RANGER R13UH88/UH9E XP/CREW 13-16 0214-1105 0214-1105 RZR 800 4X4-4 SEATER 11-14 0214-0755 0214-0755
900 RANGER R13TH90DG DIESEL/DIESEL CREW 11-14 0214-1103 0214-1104 RZR 800 4X4-EXC. S SERIES & 4 SEATER 11-14 0214-0740 0214-0740
900 RZR XP 11-14 0214-1087 0214-1087 RZR 800 4X4-S SERIES 11-14 0214-0755 0214-0755
900 RZR XP 15-16 RZR 4 0214-1199 0214-1199 RZR 900 4X4 12-14 0214-0758 0214-0758
900 RZR XP 60” (ALL) 15-16 0214-1199 0214-1199 YAMAHA
900 RZR XP S 50” 15-16 0214-1198 0214-1198 GRIZZLY 550/700 07-14 4X4 0214-0738 0214-0738
925 RZR TURBO 16 0214-1195 0214-1195 GRIZZLY 660 03-08 4X4 0214-0747 0214-0748
1000 RANGER 15-16 0214-1105 0214-1105 RHINO 450/660/700 04-13 4X4 0214-0751 0214-0752
1000 RZR XP 14-15 0214-1099 0214-1099
1000 RZR S 60” 16 0214-1199 0214-1199
1000 RZR XP 16 0214-1195 0214-1195
1000 SCRAMBLER XP 14-15 0214-1089 0214-1089 LEFT HAND RIGHT HAND
1000 SPORTSMAN 15 0214-1089 0214-1089 FITS MODEL AXLE PART # AXLE PART #
1000 GENERAL 16 0214-1199 0214-1199 REAR HEAVY DUTY AXLES
EV RANGER 13-15 0214-1090 0214-1090 ARCTIC CAT
SUZUKI PROWLER 700 08 4X4 0214-0762 0214-0762
450 KING QUAD 07-09 0214-1109 0214-1109 PROWLER 700 09-10 4X4-XTX 0214-0762 0214-0762
500 KING QUAD 09, 11-14 0214-1109 0214-1109 CAN-AM
700 KING QUAD 05-07 0214-1109 0214-1109 COMMANDER 800/1000 11-15 4X4 0214-0768 0214-0768
750 KING QUAD 08-09, 11-14 0214-1109 0214-1109 KAWASAKI
YAMAHA BRUTE FORCE 650I 06-13 4X4 0214-0742 0214-0742
350 GRIZZLY 07-11 0214-1137 0214-1137 BRUTE FORCE 750I 05-13 4X4 0214-0742 0214-0742
400 BIG BEAR 07-12 0214-1138 0214-1139 TERYX 750 08-13 4X4-EXC. TERYX4 - 0214-0766
400 GRIZZLY 08 0214-1137 0214-1137 POLARIS
400 GRIZZLY 07 0214-1128 0214-1128 RANGER 800 4X4-11-13 0214-0757 0214-0757
400 KODIAK 05-06 0214-1128 0214-1128 RANGER 800 4X4-FULL-SIZE W/54” BED BOX 14 0214-0757 0214-0757
450 GRIZZLY 11-14 0214-1140 0214-1140 RANGER 900 4X4-EXC DIESEL 13-14 0214-0757 0214-0757
450 GRIZZLY 08-10 0214-1137 0214-1137 RZR 570 4X4 12-14 0214-0760 0214-0760
450 GRIZZLY 07 0214-1128 0214-1128 RZR 800 4X4-08 0214-0741 0214-0741
450 KODIAK 05-07 0214-1128 0214-1128 RZR 800 4X4-EXC. S SERIES 09-10 0214-0741 0214-0741
450 RHINO 06-09 0214-1132 0214-1133 RZR 800 4X4-S SERIES-09-10 0214-0756 0214-0756
550 GRIZZLY 09-14 0214-1136 0214-1136 RZR 800 4X4-4 SEATER-EXC. INTL. 11-14 0214-0756 0214-0756
660 GRIZZLY 03-08 0214-1121 0214-1122 RZR 800 4X4-EXC. S SERIES & 4 SEATER 11-14 0214-0741 0214-0741
660 RHINO 06-07 0214-1132 0214-1133 RZR 800 4X4-S SERIES-EXC. INTL 11-14 0214-0756 0214-0756
700 GRIZZLY 14-15 0214-1141 0214-1141 RZR 900 4X4-12-14 0214-0759 0214-0759
700 GRIZZLY 07-13 0214-1136 0214-1136 YAMAHA
700 RHINO 08-09, 11-13 0214-1134 0214-1135 GRIZZLY 550/700 07-14 4X4 0214-0739 0214-0739
700 WOLVERINE 16 0214-1142 0214-1142 GRIZZLY 660 03-08 4X4 0214-0749 0214-0750
700 VIKING 14-16 0214-1142 0214-1142 RHINO 450/660/700 04-13 4X4 - 0214-0754
