5-SPEED TRANSMISSION ASSEMBLIES
•Gears and shafts are CNC-machined from materials that exceed 8620 steel
HANDLEBARS, •Hand-assembled and matched for a 0,0002” tolerance between the shafts
CONTROLS & •Assemblies include natural finish case, chrome trap door, side cover, top cover
MIRRORS and hardware
•Available with standard or close-ratio first-gear sets
•Requires 87-14 style clutch cable
•All parts are made in the U.S.A. and assembled in JIMS Machining’s technologically
CABLES advanced facility
PART # DESCRIPTION
5‑SPEED FOR USE IN A 4‑SPEED SHOVELHEAD RIGID‑MOUNT FRAME (70‑E84 KEYED MAINSHAFT)
DS‑325777 Standard ratio
BRAKES DS‑325778 Close ratio

OIL TANKS,
FILTERS &
GAS TANKS

DASHES
& GAUGES DS-194500

CHASSIS,
SUSPENSION, 4-SPEED GEAR SETS
FENDERS •Gears are made from high-nickel alloy steel, heat-treated and shot-
& WHEELS peened to give maximum durability and strength
•Where applicable, drive dogs have milled lead-in ramps to improve
shifting and reduce wear
FLOORBOARDS •Sets include gears, shifter dogs and shifter forks
& PEGS •Mainshaft, countershaft, bushings, bearings, snap rings, gaskets and
lock washers must be ordered separately
CLOSE RATIO 5-SPEED GEAR SET •Available in stock or close ratio
•Gears are made from high-nickel alloy steel that is heat-treated and •Made in the U.S.A.
HARDWARE shot-peened for maximum durability and strength FOR 66‑E84 SHOVELHEAD
•Drive dogs have milled lead-in ramps to improve shifting and reduce wear PART # DESCRIPTION
•Sets include gears, mainshaft and countershaft CLOSE RATIO SETS (2,44:1 FIRST GEAR/1,35:1 THIRD GEAR RATIO)
•For ease of installation, use transmission rebuild kits PART #DS-325779 DS‑194498 For 77-E84
•Includes close ratio 2,94:1 first gear DS‑194499 For 66-76
GENERAL •Made in the U.S.A. STOCK RATIO SETS (2,60:1 FIRST GEAR/1,23:1 THIRD GEAR RATIO)
PART # DESCRIPTION DS‑194497 For 77-E84
1106‑0058 For 81-83 FLT/ FLHT; 82-83 FXR models DS‑194500 For 66-76
