OIL PUMP FOR SHOVELHEAD
•Sold individually unless noted
GASKETS REF # PART # OEM # DESCRIPTION MFG.
& SEALS FOR 66-84 SHOVELHEAD
1
1 DS-245276 45830-48 Hex socket plug, /8” male NPT, 66-84 Gardner-Westcott
2 DS-174428 26258-68B Oil pump cover gasket, Mylar, 68-E80 (10-pk.) Genuine James
2 DS-174720 26258-68D Oil pump cover gasket, black paper, 68-E80 (10-pk.) Genuine James
ELECTRICAL 2 DS-174829 26276-80A Oil pump cover gasket, black paper, L80-84 (10-pk.) Genuine James
& LIGHTING 2 DS-173464 26276-80A Oil pump cover gasket, Mylar, L80-84 (10-pk.) Genuine James
2 DS-174690 26257-50A Oil pump cover gasket, black paper, 66-67 (10-pk.) Genuine James
3 2106-0135 26552-72 Oil pressure switch, 66-84 Standard Motor Products
3 DS-272158 26552-72 Oil pressure switch, 66-84 Drag Specialties
HANDLEBARS, 4 DS-174433 26348-36 Oil pump shaft end C-clip, 66-84 (10-pk.) Genuine James
CONTROLS & 4 DS-188051 26348-36 Oil pump shaft snap ring, 66-84 (10-pk.) Eastern
MIRRORS 5 DS-197050 26326-62A Oil pump feed idler gear, 66-84 JIMS
6 DS-197051 26328-74 Oil pump feed drive gear, 66-84 JIMS
7 DS-194425 26227-58 Oil pump seal, 68-84 (5-pk.) Genuine James
8 DS-173404 8873 Check valve ball, 66-84 (10-pk.) Genuine James
CABLES 9 DS-194222 26262-80 Check valve spring, 81-84 (10-pk.) Eastern
9 DS-194223 26363-41 Check valve spring, 66-80 (10-pk.) Eastern
10 DS-174334 11105 Oil screen/ pump plug O-ring, 71-84 (25-pk.) Genuine James
11 2401-0107 26263-80 Oil screen plug, Allen-style, 81-84 Colony
11 0932-0056 26263-80 Oil screen plug, chrome, 81-84 Colony
BRAKES 11 0932-0057 26263-80 Oil screen plug, cadmium, 81-84 Colony
12 DS-173516 26231-78 Oil pump plug washer (brass), 66-80 (10-pk.) Genuine James
12 DS-174426 26231-78 Oil pump plug washer (blue PTFE), 66-80 (10-pk.) Genuine James
13 0932-0075 26400-82 Oil pump relief valve plunger, L82-84 Eastern
OIL TANKS, 14 DS-194207 26207-83 Relief valve spring, L83-84 (10-pk.) Eastern
FILTERS & 14 0932-0104 26207-83 Relief valve spring, 66-84 S&S
GAS TANKS 15 DS-197039 26315-68A Oil pump return drive gear, 66-84 JIMS
16 DS-197040 26317-68A Oil pump return idler gear, 66-84 JIMS
17 DS-197038 26346-69/70 Oil pump drive shaft, 68-84 JIMS
DASHES 17 DS-197037 26346-36 Oil pump drive shaft, 66-67 JIMS
& GAUGES 18 DS-173529 11002 Oil pump shaft snap ring, 70-84 (10-pk.) Genuine James
18 DS-173403 11002 Oil pump retainer clip. 70-84 (10-pk.) Eastern
19 DS-194206 26348-15 Oil pump key, 68-84 (10-pk.) Genuine James
CHASSIS, 20 DS-174730 26246-68D Oil pump body to motor gasket, black paper, 68-E80 (10-pk.) Genuine James
SUSPENSION, 20 DS-174427 26246-68A Oil pump body to motor gasket, Mylar, 68-E80 (10-pk.) Genuine James
FENDERS 20 DS-174826 26273-80B Oil pump body to motor gasket, black paper, L80-84 (10-pk.) Genuine James
& WHEELS 20 DS-174480 26245-41 Oil pump body to motor gasket, black paper, 66-67 (10-pk.) Genuine James

FLOORBOARDS OIL PUMP MOUNTING HARDWARE
1
& PEGS • /4”-24 hard-to-find hex nuts come in a six-pack
1
•The /4”-24 thread oil pump nut is an exact reproduction of
66-67 Shovelhead oil pump nuts
•OEM style kit is a complete kit that includes studs, nuts and hex nuts 0932-0061
HARDWARE •Available in cadmium, parkerized or chrome-plated 0932-0067
•Made in the U.S.A. 0932-0064
FOR 66-67 SHOVELHEAD
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
COMPLETE KIT NUT KIT LONG NUT REPL. OEM #24831-41
GENERAL 0932-0066 Chrome 0932-0060 Chrome 0932-0063 Chrome
0932-0067 Cadmium 0932-0061 Cadmium 0932-0064 Cadmium
0932-0068 Parkerized 0932-0062 Parkerized 0932-0065 Parkerized
