SHOVELHEAD

33-4226
SEATS &
PINION/ SISSY BARS
GEAR COVER
GENERATOR DOWEL PINS
CRANKCASE •0,125” x 0,250” long EXHAUST
GEAR KITS 31-2037 31-2039 •Made in the U.S.A.
•Include circuit breaker drive gear, idler gear assembly and PART # DESCRIPTION
For 66-84 Shovelhead (25-pk.); repl. OEM #275
0925‑0531
circuit breaker shaft gear with shims
•Circuit breaker gear shaft and idler gear shaft sold separately PINION GEARS CARBURETORS
•Made in the U.S.A. & AIR FILTERS
•High-quality pinion
PART # DESCRIPTION gears are carefully
FOR 66‑69 SHOVELHEAD machined, heat
33‑4226 Gear kit (standard clockwise rotation) treated and then finish ground
31‑2037 Circuit breaker gear shaft; repl. OEM #25856-36 •Available in various sizes ENGINE
31‑2039 Idler gear shaft; repl. OEM #25791-36 •Sold each

•Made in the U.S.A. DS-194247 DS194473
COLOR PART # OEM # SIZE
FOR L77‑84 SHOVELHEAD TRANSMISSION
Yellow DS‑194247 24042-78 1,4737” - 1,4745” & DRIVELINE
Red DS‑194248 24043-78 1,4729” - 1,4737”
CIRCUIT BREAKER SHAFT KIT Blue DS‑194249 24044-78 1,4721” - 1,4729”
•Circuit breaker shaft kit consists of a shaft Green DS194483 24045-78 1,4715” - 1,4721”
and two replacement bushings FOR 66‑E77 SHOVELHEAD GASKETS
•Made in the U.S.A. Red DS194472 24010-54 1,4475” - 1,4480” & SEALS
PART # DESCRIPTION Blue DS194473 24010-54 1,4470” - 1,4475”
Green
DS194474
24010-54
1,4465” - 1,4470”
DS‑194234 For 66-69 Shovelhead; repl. OEM #s 25856-36, 25785-30A White DS194477 24010-54 1,4460” - 1,4465”

ELECTRICAL
DS-194192 & LIGHTING
IDLER GEAR STEEL BREATHER
AND CIRCUIT VALVE WASHER KITS
BREAKER •PART #DS-194159 includes HANDLEBARS,
BUSHINGS/ one each of the following DS-194159 CONTROLS &
STUDS size washers: 0,110”; 0,115”; MIRRORS
•Idler gear 0,120”; 0,125”; 0,130”; 0,135”;
bushings/ studs 0,140” and 0,145” (0,313” i.d. hole)
•Also works for circuit •PART #0950-0364 includes one each of the CABLES
breakers as noted below following size washers: 0,110”; 0,115”; 0,120” and
0,125” (0,195” i.d. hole)
•Made in the U.S.A. DS-195007 DS-188049 •Replacement washers sold in 5-packs
PART # DESCRIPTION •Made in the U.S.A. 0950-0364
DS‑194192 Idler gear bushings for 66-69 Shovelhead; circuit breaker PART # DESCRIPTION
bushings for 66-69 Shovelhead (pr.); repl. OEM #25785-30A BRAKES
DS‑195007 Idler gear stud with bushing for 66-69 Shovelhead; FOR L79‑82 SHOVELHEAD
repl. OEM #s 25791-36, 25785-30A DS‑194159 8-piece washer kit
DS‑188049 Idler and circuit breaker stud snap rings for 66-69 FOR 66‑E79 SHOVELHEAD
Shovelhead (10-pk.); repl. OEM #25810-15 0950‑0364 4-piece washer kit OIL TANKS,
FILTERS &
STEEL BREATHER GAS TANKS
GEAR KITS
PLASTIC BREATHER •Kit comes with gear
and spacer
VALVE WASHER SET •Available in standard or +0,030” oversize DASHES
& GAUGES
•Available in plastic style •Require the use of corresponding cam
•Sold in sets of eight of and pinion gear
varying thickness •Made in the U.S.A. DS-194242 CHASSIS,
•Made in the U.S.A. PART # DESCRIPTION SUSPENSION,
NOTE: Use only plastic washers with plastic breather valves. STANDARD FENDERS
Do not intermix plastic and steel parts. DS‑194242 For L77-84 Shovelhead; repl. OEM #25313-77B & WHEELS
PART # DESCRIPTION DS‑194243 For 66-E77 Shovelhead; repl. OEM #25313-73
FOR 82‑84 SHOVELHEAD +0,030” OVERSIZE
DS‑194160 Plastic washer set; 0,130”; 0,135”; 0,140”; 0,145”; DS194471 For L77-84 Shovelhead FLOORBOARDS
0,150”; 0,155”; 0,160” and 0,165”; repl. OEM #25320-82 DS194469 For 66-E77 Shovelhead & PEGS

BREATHER SEPARATOR HARDWARE
PLATE AND SCREEN
•Exact OEM replicas
•Screen and plates are sold separately
•Made in the U.S.A. 0950-0343 0950-0352
PART # DESCRIPTION PART # DESCRIPTION GENERAL
FOR 66‑69 SHOVELHEAD FOR 66‑69 SHOVELHEAD (CONT)
0950‑0343 Separator plate (5-pk.); repl. OEM #25279-36 0950‑0352 Breather screen (5-pk.); repl. OEM #25275-36

ALL PART NUMBERS IN BLUE ARE NEW 81
