Page 82 - Oldbook 2017

SHOVELHEAD

0924‑0263
SEATS & 0925‑0579
SISSY BARS

EXHAUST 0924‑0013

0925‑0578
CARBURETORS
& AIR FILTERS CAMSHAFT DRIVE GEARS
•Available in undersize, standard and oversize
0924‑0272 •Made in the U.S.A.
CAM BEARINGS/ BUSHINGS NOTE: Measured of 0,105 gauge pins. Measuring the same gear
DS‑194147
ENGINE PART # DESCRIPTION with 0,108 pins will show a 0,012 larger measurement.
INNER CAM NEEDLE BEARING GEAR PART # SIZE COLOR
0924‑0263 For 66‑84 Shovelhead (ea.); repl. OEM #9058 FOR 78‑84 SHOVELHEAD
0924‑0013 For 66‑84 Shovelhead (Timken) (ea.); repl. OEM #9058 Undersize 0925‑0577 2,7324 Orange
CAM COVER BUSHINGS Std. 0925‑0579 2,7364 Red
TRANSMISSION DS‑194198 For 70‑84 Shovelhead (ea.); repl. OEM #25581‑70 Oversize 0925‑0581 2,7384 Black
& DRIVELINE 0924‑0272 For 70‑84 Shovelhead (+0,005”) (ea.); repl. OEM #25581‑70 FOR 70‑77 SHOVELHEAD
0924‑0271 For 70‑84 Shovelhead (+0,010”) (ea.); repl. OEM #25581‑70 Undersize 0925‑0578 2,7670 Black
DS‑194147 For 66‑69 Shovelhead (ea.); repl. OEM #25581‑36

GASKETS
& SEALS

ELECTRICAL CAM COVER BUSHINGS
& LIGHTING •Bushings are made from solid bronze bar stock
•Machined in one operation with a tolerance of 0,0002”
•Features a lead‑in for ease of installation DS‑197069
HANDLEBARS, •Sold each DS‑194194
CONTROLS & •Made in the U.S.A.
MIRRORS PART # DESCRIPTION
DS‑197069 For 70‑84 Shovelhead (1,2015” o.d.); repl. OEM #25581‑70 DS‑194195
DS‑197055 For 70‑84 Shovelhead (+0,005” o.d.)
DS‑197068 For 66‑69 Shovelhead (1,0035” o.d.); repl. OEM #25581‑36
CABLES CAM BUSHING KITS
•Kits include cam and gear shaft
bushings/ bearings, along with lock
pins and thrust plate
BRAKES •All parts are standard sizes DS‑194193
•Made in the U.S.A.
PART # DESCRIPTION
DS‑194195 For 73‑84 Shovelhead; repl. OEM #s 275,
OIL TANKS, DS‑194162 9058, 25550‑57, 25581‑70, 25582‑73
FILTERS & DS‑194194 For 70‑72 Shovelhead; repl. OEM #s 275,
GAS TANKS CAM SHIMS 9058, 25550‑57, 25581‑70, 25582‑54
•Available in a set of 10, or in individual sizes in 5‑pk. 0925‑0288 DS‑194193 For 66‑69 Shovelhead; repl. OEM #s 275,
9058, 25550‑57, 25581‑36, 25582‑54, 25785‑30A
•Made in the U.S.A.

DASHES PART # DESCRIPTION
& GAUGES FOR 66‑84 SHOVELHEAD
DS‑194162 10‑piece set (0,050” thru 0,095”)
0925‑0288 0,040”
CHASSIS, 0925‑0289 0,045”; repl. OEM #25555‑48 CAM LOCK
SUSPENSION, DS‑194163 0,050”; repl. OEM #25550‑36 WASHERS
FENDERS DS‑194164 0,055”; repl. OEM #25551‑36
& WHEELS DS‑194165 0,060”; repl. OEM #25552‑36 •Sold in 5‑pks.
DS‑194166 0,065”; repl. OEM #25553‑36 •Made in the U.S.A.
DS‑194167 0,070”; repl. OEM #25554‑36 PART # DESCRIPTION
FLOORBOARDS DS‑194168 0,075”; repl. OEM #25555‑36 DS‑193144 For 66‑84 Shovelhead; repl. OEM #25550‑57A
& PEGS DS‑194169 0,080”; repl. OEM #25556‑79

HARDWARE PINION SHAFT BUSHING
•Made from solid brass bar stock
•Available in stock and oversize
PINION SHAFT BUSHING •Sold each
•Quality pinion shaft bushing; sold individually •Made in the U.S.A. 0924‑0273
GENERAL •Made in the U.S.A. PART # DESCRIPTION PART # DESCRIPTION
PART # DESCRIPTION FOR 73‑84 SHOVELHEAD FOR 73‑84 SHOVELHEAD (CONT)
DS‑194180 For 66‑84 Shovelhead; repl. OEM #25582‑54, 73 0924‑0273 Std.; repl. OEM #25582‑73 0924‑0274 +0,005”

80 ALL PART NUMBERS IN BLUE ARE NEW
