SHOVELHEAD

SEATS &
SISSY BARS

EXHAUST

CAM CHEST FOR SHOVELHEAD (CONT) CARBURETORS
REF # PART # OEM # DESCRIPTION MFG. & AIR FILTERS
FOR 66-84 SHOVELHEAD (CONT)
11 DS-194162 - Cam shim set, 0,050” through 0,095”, 66-84 (10-piece) Eastern
11 0925-0288 - Cam shim, 0,040”, 66-84 (5-pk.) Eastern
11 0925-0289 25555-48 Cam shim, 0,045”, 66-84 (5-pk.) Eastern ENGINE
11 DS-194163 25550-36 Cam shim, 0,050”, 66-84 (5-pk.) Eastern
11 DS-194164 25551-36 Cam shim, 0,055”, 66-84 (5-pk.) Eastern
11 DS-194165 25552-36 Cam shim, 0,060”, 66-84 (5-pk.) Eastern
11 DS-194166 25553-36 Cam shim, 0,065”, 66-84 (5-pk.) Eastern
11 DS-194167 25554-36 Cam shim, 0,070”, 66-84 (5-pk.) Eastern TRANSMISSION
11 DS-194168 25555-36 Cam shim, 0,075”, 66-84 (5-pk.) Eastern & DRIVELINE
11 DS-194169 25556-79 Cam shim, 0,080”, 66-84 (5-pk.) Eastern
12 0925-0739 - OE-type hydraulic camshaft, 66-69 w/ generator-style crankcases S&S
12 0925-0740 - OE-type hydraulic camshaft, 70-77 w/ alternator-style crankcases S&S
12 0925-0741 - OE-type hydraulic camshaft, 78-84 w/ alternator-style crankcases S&S GASKETS
13 DS-194198 25581-70 Cam cover bushing, std., 70-84 Eastern & SEALS
13 0924-0272 - Cam cover bushing, +0,005”, 70-84 Eastern
13 0924-0271 - Cam cover bushing, +0,010”, 70-84 Eastern
13 DS-194147 25581-36 Cam cover bushing, 66-69 Eastern
13 DS-197069 25581-70 Cam cover bushing (1,2015” o.d.), 70-84 JIMS ELECTRICAL
13 DS-197055 - Cam cover bushing (+0,005” o.d.), 70-84 JIMS & LIGHTING
13 DS-197068 25581-36 Cam cover bushing (1,0035” o.d.), 66-69 JIMS
14 0925-0531 275 Pinion/ gear cover dowel pins, 66-84 (25-pk.) Eastern
15 DS-194325 23985-54 Gear shaft pinion key, 66-84 (10-pk.) Eastern HANDLEBARS,
15 DS-194206 26348-15 Oil pump key, 68-84 (10-pk.) Genuine James CONTROLS &
16 DS-194007 26349-73A Oil pump drive gear, 73-84 Eastern MIRRORS
16 0932-0033 26349-54 Oil pump drive gear, 66-72 Eastern
16 DS-194245 26349-73A Oil pump drive gear, 73-84 S&S
17 0950-0288 24703-54 Pinion shaft gear spacer, 66-84 Eastern
18 DS194472 24010-54 Pinion gear, 1,4475” - 1,4480”, red, 66-E77 S&S CABLES
18 DS194473 24010-54 Pinion gear, 1,4470” - 1,4475”, blue, 66-E77 S&S
18 DS194474 24010-54 Pinion gear, 1,4465” - 1,4470”, green, 66-E77 S&S
18 DS194477 24010-54 Pinion gear, 1,4460” - 1,4465”, white, 66-E77 S&S
18 DS-194247 24042-78 Pinion gear, 1,4737” - 1,4745”, yellow, L77-84 S&S
18 DS-194248 24042-78 Pinion gear, 1,4729” - 1,4737”, red, L77-84 S&S BRAKES
18 DS-194249 24042-78 Pinion gear, 1,4721” - 1,4729”, blue, L77-84 S&S
18 DS194483 24042-78 Pinion gear, 1,4715” - 1,4721”, green, L77-84 S&S
19 DS-194325 23485-54 Gear shaft pinion keys, 66-84 (10-pk.) Eastern
19 DS-194206 26348-15 Oil pump key, 68-84 (10-pk.) Genuine James OIL TANKS,
20 DS-198839 24023-54 Gear-side pinion shaft nut, 66-84 JIMS FILTERS &
21 0925-0531 275 Pinion/ gear cover dowel pins (25-pk.) Eastern GAS TANKS
22 DS-194180 25582-54/ 25582-73 Pinion shaft bushing, 66-84 JIMS
22 0924-0273 25582-73 Pinion shaft bushing, std., 73-84 Eastern
22 0924-0274 - Pinion shaft bushing, 73-84, +0,005” Eastern
23 2011-1499 25225-36C Cam cover gasket, AFM, 68-69 (5-pk.) Cometic DASHES
23 DS-174510 25225-36C Cam cover gasket, paper, 66-69 (5-pk.) Genuine James & GAUGES
23 0934-1184 25225-36CX Cam cover gasket, paper w/ silicone, 66-69 (5-pk.) Genuine James
23 2011-1497 25225-70XM Cam cover gasket, AFM, 70-84 (5-pk.) Cometic
23 2011-2094 25225-70XM Cam cover gasket, metal core, 70-84 (10-pk.) Genuine James CHASSIS,
23 DS-174200 25225-70B Cam cover gasket, paper, 70-84 (5-pk.) Genuine James SUSPENSION,
23 DS-174201 25225-70B Cam cover gasket, paper w/ silicone, 70-84 (5-pk.) Genuine James FENDERS
24 0940-0939 25268-84A Polished billet cam cover kit, 73-84 S&S & WHEELS
24 0940-0300 25268-84A Chrome billet cam cover kit, 73-84 S&S
24 0940-0785 25268-84A Cam cover, 73-84 Drag Specialties
25 0935-0171 83162-51DL Cam housing point seal (double lip), 70-84 (5-pk.) Cometic FLOORBOARDS
25 DS-194464 83162-51 Cam housing point seal (single lip/ metal o.d.), 70-84 (5-pk.) Genuine James & PEGS
25 DS-194460 83162-51 Cam housing point seal (double lip), 70-84 (5-pk.) Genuine James
26 DS-194243 25313-73 Steel breather gear set, 66-E77 S&S
26 DS-194242 25313-77B Steel breather gear set, L77-84 S&S
27 DS-194160 25320-82 Plastic breather valve washer set (0,130”; 0,135”; 0,140”; 0,145”; 0,150”; 0,155”; 0,160” and 0,165”), 82-84 Eastern HARDWARE
28 2402-0089 6099 Side cover washer, 66-84 (100-pk.) Diamond Engineering
29 DS-190867 - Smooth cam cover bolt set, 70-84 Drag Specialties
29 DS-190865 - Knurled cam cover bolt set, 70-84 Drag Specialties
30 2130-0047 32606-82/ 32601-80 Ignition cover timer studs, 80-84 (10-pk.) Drag Specialties
30 2401-0464 32606-82/ 32601-80 Ignition cover timer stud kit, 80-84 Colony
30 DS242294 32606-82/ 32601-80 Ignition cover timer stud kit, 80-84 Delkron GENERAL
31 DS-174240 32591-70 Point/ ignition cover gasket, 71-78 (paper) (10-pk.) Genuine James
31 DS-174435 32591-80 Point/ ignition cover gasket, 80-84 (paper) (10-pk.) Genuine James

79
ALL PART NUMBERS IN BLUE ARE NEW
