GENERAL

DS189002

DS189003
TIRES &
DS189004 DS189005 DS189006 TUBES

DS189007 DS189009

DS189008
STORAGE DRAWERS AND RACKS
•Storage drawers are available in two sizes and four layouts
1
3
•Small drawers measure 13 /8” W x 2” H x 9 /4” D; large drawers measure
18” W x 3” H x 12 /2” D
1
•Drawers are available with 12, 16, 20 and 24 compartments
3
1
1
•Small rack holds six small drawers and measures 15 /4” W x 16 /4” H x 11 /4” D
1
1
•Large rack holds four large drawers and measures 20 /4” W x 15” H x 12 /2” D DS189010 DS189011 CHEMICALS,
•Drawers and racks sold separately HARDWARE
•Made in the U.S.A. & TOOLS
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
SMALL DRAWERS AND RACK SMALL DRAWERS AND RACK (CONT) LARGE DRAWERS AND RACK (CONT)
DS189002 Small rack DS189006 24‑compartment drawer DS189009 16‑compartment drawer
DS189003 12‑compartment drawer LARGE DRAWERS AND RACK DS189010 20‑compartment drawer
DS189004 16‑compartment drawer DS189007 Large rack DS189011 24‑compartment drawer
DS189005 20‑compartment drawer DS189008 12‑compartment drawer

DS‑188051
DS‑188029
DS‑188008
DS‑188013
1132‑0270
LICENSE
SNAP RINGS/ RETAINING RINGS FOR BIG TWIN AND XL PLATE
•High‑quality OEM replacement components FRAMES
•Each part number is sold in 10‑pk. 1106‑0018 DS‑188075
PART # OEM # DESCRIPTION FITS MODEL
1132‑0270 11000 Release finger 37‑84 Big Twin
DS‑188008 11007 Pinion shaft bearing and cages 58‑84 Big Twin
DS‑188011 11015 Front handle m/c 72‑81 Big Twin, 73‑81 XL
DS‑188012 11016 Shifter lever pin 5‑speed 80‑84 Big Twin
DS‑188013 11019 Clutch lever stud 80‑84 Big Twin
DS‑188016 11031 Foot shift lever and pivot pin 65‑73 Big Twin, 77‑79 XL
DS‑188018 11036 Shifter fork shaft 76‑84 Big Twin, 72‑85 XL
DS‑188027 11046 Clutch adj. screw 84‑85 XL
DS‑188022 11067 Main and countershafts 5‑speed 80‑84 Big Twin
DS‑188023 11083 Shifter cam 5‑speed 80‑84 Big Twin
DS‑188029 11096 Clutch push rod ( 3 /4 ring) 4‑ and 5‑speed 75‑84 Big Twin
DS‑188030 11096A Clutch push rod (full ring) 4‑ and 5‑speed 75‑84 Big Twin
DS‑188031 11143 H/ bar lever pivot pin (brake and clutch) 82‑84 Big Twin, 82‑85 XL
DS‑188032 11150 Shifter rod lever 5‑speed 84‑84 Big Twin
0632‑0334 11155 Throttle screw 75‑84 Big Twin, 79‑85 XL
DS‑188037 11164 Clutch hub bearing 84‑85 XL
DS‑188049 25810‑15 Idler and circuit breaker studs 36‑69 Big Twin WINDSHIELDS
DS‑188051 26348‑36 Oil pump shaft 36‑84 Big Twin
1106‑0018 34040‑52 Shifter cam 4‑speed 79‑84 Big Twin, 52‑85 XL
DS‑188066 35129‑36 Mainshaft race 4‑speed 37‑77 Big Twin
DS‑188067 35337‑36 M/S third gear 4‑speed 36‑84 Big Twin
DS‑188069 35810‑36 C/S second gear 4‑speed 37‑84 Big Twin
DS‑188084 35920‑36 C/S bearings 36‑77 Big Twin
1132‑0278 36797‑84 Clutch pressure plate 84‑85 XL
DS‑188073 37904‑84 Clutch bearing 84 Big Twin
DS‑188075 37907‑84 Pressure plate 5‑speed 84 Big Twin
