SHOVELHEAD

SEATS &
SISSY BARS

EXHAUST

CARBURETORS REPLACEMENT DS-750598
& AIR FILTERS
PISTON RINGS
•Available in standard and
oversize versions
•Feature a cast or moly
ENGINE
top ring
•Reverse torsional taper
face second ring and easy
“spiral on” three-piece oil rings
TRANSMISSION NOTE: Each PART # includes enough rings
& DRIVELINE for two pistons except where noted.
DESCRIPTION MOLY CAST DESCRIPTION MOLY CAST
FOR 78‑E83 1340CC SHOVELHEAD FOR 66‑80 1200CC SHOVELHEAD (CONT)
GASKETS Standard DS‑750830 DS‑750630 NOTE: Has 0,0625” compression rings. (CONT) DS-750599
& SEALS +0,005 DS‑750867 ‑ +0,050 DS‑750825 DS‑750625
+0,010 DS‑750831 DS‑750631 +0,060 DS‑750826 DS‑750626
+0,020 DS‑750832 DS‑750632 +0,070 DS‑750827 DS‑750627 PISTON
+0,030 DS‑750833 DS‑750633 FOR 66‑80 SHOVELHEAD 3,625” BIG BORE KB PISTONS PIN CLIPS
ELECTRICAL +0,040 DS‑750834 DS‑750634 NOTE: Big bore sets include enough rings for one •Quality equals
& LIGHTING +0,050 ‑ DS‑750855 piston only. You must order two sets for complete or exceeds OEM
FOR 66‑80 1200CC SHOVELHEAD motor. These rings consist of two 0,0625” com‑
NOTE: Has 0,0625” compression rings. pression rings and one 0,1875” oil control ring. specifications
Standard DS‑750820 DS‑750620 Standard DS‑750861 ‑ •Made in the U.S.A.
HANDLEBARS, +0,005 DS‑750868 ‑ +0,005 DS‑750862 ‑ PART # DESCRIPTION
CONTROLS & +0,010 DS‑750821 DS‑750621 +0,010 DS‑750863 ‑ DS‑750598 For L77-83 Shovelhead
MIRRORS +0,020 DS‑750822 DS‑750622 +0,020 DS‑750864 ‑ (10-pk.); repl. OEM #22588-78
+0,030 DS‑750823 DS‑750623 +0,030 DS‑750865 ‑ DS‑750599 For 73-E77 Shovelhead
+0,040 DS‑750824 DS‑750624 (10-pk.); repl. OEM #22582-52

CABLES DS-750605

DS-750604
0931-0075
BRAKES

OIL TANKS,
FILTERS &
GAS TANKS

DASHES
& GAUGES

CHASSIS,
SUSPENSION,
FENDERS
& WHEELS
CYLINDERS
•Cast-iron cylinders meet or exceed OEM
FLOORBOARDS tolerance specifications
& PEGS •Withstand greater pressure and heat than stock SHOVELHEAD CYLINDER KITS
•Available in front and rear versions •5,330” cylinder length for 4,250” stroke
•Sold each •Available for stock 3,4375” bore and big bore 3,625”
NOTE: All Shovelhead cylinders require the use of 12-point head bolts, •Kits include front and rear cylinders, base nuts,
HARDWARE PART #DS-190796. headbolts, base gaskets and head gaskets
NOTE: Due to the many different brands of pistons that are available, •Both kits come with a glossy black finish
all cylinders listed below will need to be sized and clearanced to •Made in the U.S.A.
the type of piston being used. NOTE: 3,625” bore cylinders require crankcase machining.
PART # DESCRIPTION PART # DESCRIPTION
GENERAL FOR 66‑80 1200CC SHOVELHEAD FOR 66‑84 SHOVELHEAD
DS‑750605 3,435” front; repl. OEM #s #16484-66B, 16485-74A 0931‑0381 3,4375” bore kit
DS‑750604 3,435” rear; repl. OEM #s #16492-66B, 16492-74A 0931‑0075 3,625” bore kit

66 ALL PART NUMBERS IN BLUE ARE NEW
