Page 625 - Oldbook 2017

IRONHEAD XL

DS‑242028 SEATS &
SISSY BARS
DS‑242407

EXHAUST
DS‑242026 DS‑242027

POINTS AND CONDENSERS CARBURETORS
•Contact sets feature a metal spring designed to resist metal fatigue DS‑242410 & AIR FILTERS
and a follower of space‑age material to ensure longer life
•Condenser is sealed to help prevent breakdown due to moisture
•Meet or exceed OEM specs
•Sold in kits or as individual components ENGINE
PART # DESCRIPTION PART # DESCRIPTION
KITS INDIVIDUAL COMPONENTS
DS‑242026 For 71‑E78 XL DS‑242407 Points for 71‑E78 XL; repl. OEM #32661‑70
DS‑242027 For 57‑70 XL DS‑242406 Points for 57‑70 XL; repl. OEM #30605‑48 TRANSMISSION
DS‑242028 For 58‑69 XL w/ magneto DS‑242408 Points for 58‑69 XLCH (magneto); repl. OEM #29533‑55A & DRIVELINE
DS‑242410 Condenser for 57‑E78 XL; repl. OEM #32726‑30A
DS‑242409 Condenser for 58‑69 XLCH (magneto); repl. OEM #29534‑55A

GASKETS
& SEALS

STAINLESS STEEL ELECTRICAL
SENSOR PLATE SCREWS & LIGHTING
IGNITION CIRCUIT •Made from 17‑4 stainless steel
BREAKER STUDS •Strongest screws on the market today
•Replacement studs with screws and washers •The body is 0,700” long HANDLEBARS,
•Sold in a 10‑pack •Sold in pairs CONTROLS &
PART # DESCRIPTION •Made in the U.S.A. MIRRORS
2130‑0047 For 80‑85 XL; repl. OEM #s 32601‑80, PART # DESCRIPTION
32606‑82 DS242294 For 80‑85 XL; repl. OEM #32601‑80, 32601‑78

CABLES

IGNITION COVER BRAKES
TIMER STUD KITS
•Reproduction of original CIRCUIT BREAKER CIRCUIT BREAKER
ignition timer cover studs
•Zinc‑plated POST REBUILD KIT ADJUSTING SCREW KIT OIL TANKS,
•Sold in pairs 2401‑0464 •Reproduction of brass circuit breaker post •Cadmium‑plated FILTERS &
•Made in the U.S.A. •Kit includes one post and one •Works on all battery models GAS TANKS
PART # DESCRIPTION installation tool •Made in the U.S.A.
2401‑0464 For 80‑85 XL; repl. OEM #s •Made in the U.S.A. PART # DESCRIPTION
32606‑82, 32601‑80 PART # DESCRIPTION 2401‑0540 For 57‑64 XL; repl. OEM #s DASHES
2401‑0463 For 70‑79 XL; repl. OEM #32601‑78 2401‑0460 For 57‑69 XL 32593‑47, 1062, 774 & GAUGES

CHASSIS,
SUSPENSION,
FENDERS
& WHEELS

FLOORBOARDS
ELECTRONIC & PEGS
IGNITION DISTRIBUTOR
•Lightweight billet aluminum construction
•12V unilite ignition with fully adjustable advance allows faster and
ELECTRONIC IGNITION DISTRIBUTOR easier starting HARDWARE
•Lightweight billet aluminum construction •Feature advance curves, rev‑limiting and high‑spark output
•12V unilite ignition with fully adjustable advance •Can be set to run either in a single‑or dual‑fire mode
allows faster and easier starting •No head removal when using stock heads
•No head removal when using stock heads •Requires graphite plug wires and resistor spark plugs
•Made in the U.S.A. •Made in the U.S.A. GENERAL
PART # DESCRIPTION PART # DESCRIPTION
DS243087 For 57‑70 XL 2130‑0020 For 57‑70 XL

ALL PART NUMBERS IN BLUE ARE NEW 623
