IRONHEAD XL

SEATS &
Natural SISSY BARS
530 SERIES O-RING CHAIN
•Features quad-pin riveting, tough O-ring
seals, and solid bushings and rollers
•Improved wear resistance and strength EXHAUST
•Average tensile strength 9500 lb
•Weight saving with high tensile strength Chrome
•Pre-stretched at the factory
•Rivet type master link included CARBURETORS
•Chrome chain features tough chrome plating & AIR FILTERS
on side plates
FOR 57‑85 XL
